26

CLEANING OVEN GLASS
Lift by pressing on plastic latches on left and right side as shown in

Figure 22 and pulling the profile toward yourself as in Figure 23. Glass

is  released  after  profile  is  removed  as  shown  in  Figure  24.  Remove  the

released  glass  by  pulling  toward  yourself  carefully.  Outer  glass  is  fixed

to  oven  door  profile.  You  can  perform  glass  cleaning  easily  after  glasses

are released. You can mount glasses back by performing the operations

reversely after cleaning and maintenance are completed. Ensure that

profile is seated properly in place.

USING THE GRILL DEFLECTOR SHEET*
1.Place the heat shield under the control panel by opening the oven

front door. (Figure 26)

2.Locate the two mounting tabs on the heat shield into the two slots

under the control panel, then secure in place between oven and inner
door by gently closing the door. (Figure 27)

3.

lt is important to keep the dooropen the specified distance when grilling.

4.The heat shield will provide an ideal cooking performance while

protecting the control panel and knobs.

Figure 22

Figure 23

Figure 24

Figure 25

Figure 26

Figure 27

GB
