REDUCED GAS FLOW RATE SETTING FOR TAPS

1. Ignite the burner that is to be adjustment and

turn the knob to the reduced position.

2. Remove the knob from the gas tap.

3. Use an appropriately sized screwdriver to adjust

the flow rate adjustment screw. For LPG

(Butane-Pro pane) turn the screw clockwise. For

the naturel gas, you should turn the screw

counter- clockwise once.

“The normal length of a straight flame in the

reduced position should be 6-7 mm.“

4.

 If the flame is higher then the desired position,

turn the screw clockwise. If it is smaller turn

anticolockwise.

5. For the last control, bring the burner both

to higt-flame and reduced positions and check

whether the flame is on or off.

Depending on the type of gas tap used in your appliance the

adjustment screw position may vary.

To adjust your oven acc. to the gas type, make the adjustment for

reduced flame carefully by turning with a small screwdriver as shown

below on the screw in the middle of the gas cocks as well as nozzle
changes. (Figure 13 and 14)

CONTROL PANEL

The roast chicken function is optional.

Figure 13

Figure 14

5

55

10

50

15

45

20

40

25

35

30

Built in Gas Oven Control Panel Picture

MIN

140

165

220

MAX

MIN

140

165

220

MAX

5

55

10

50

15

45

20

40

25

35

30

Built in Mix Oven Control Panel Picture
