10

60 cm Built-In Oven Installation and Mounting
Place of use for product must be located before starting installation.

Product mustn’t be installed in places which are under the effect of

strong air flow.

Carry the product with minimum two people. Do not drag the product so

that floor isn’t damaged.

Remove all transportation materials inside and outside the product.

Remove all materials and documents in the product.

Installation Under Counter
Cabin must match the dimensions provided in Figure 2.

A clearance must be provided at the rear part of the cabin as indicated

in the figure so that necessary ventilation can be achieved.

After mounting, the clearance between lower and upper part of the

counter is indicated in Figure 5 with “A”. It’s for ventilation and shouldn’t

be covered.

Installation In An Elevated Cabinet
Cabin must match the dimensions provided in Figure 4.

The clearances with the dimensions indicated in the figure must be

provided at the rear part of cabin, upper and lower sections so that

necessary ventilation can be achieved.

Installation Requirements
Product dimensions are provided in the Figure 3.

Furniture surfaces for mounting and mounting materials to be used

must have a minimum temperature resistance of 100 °C.

Mounting cabin must be secured and its floor must be plane for product

not to tilt over.

Cabin floor must have a minimum strength that would handle a load of

60 kg.

Placing and Securing the Oven
Place the oven into the cabin with two or more people.

Ensure that oven’s frame and front edge of the furniture match

uniformly.

Supply cord mustn’t be under the oven, squeeze in between oven and

furniture or bend.

Fix the oven to the furniture by using the screws provided with the

GB
