TRANSFORMATION FROM NATURAL GAS TO LPG AND FROM LPG TO NATURAL GAS

Removal of the Upper Burner:
With the help of a screw driver, remove the screw as shown in Figure 6.

As shown in Figure 7, remove the burner from its place by pulling it to

yourself. As shown in Figure 8, remove the injector in the bearing with a

socket wrench and insert the injector suitable replacement. In order to

re-place the burner, apply the removal process reversely.

Removal of the Lower Burner:

The lower burner door has been fixed with two screws. As shown in

Figure 9, remove it with the help of a screw driver. Remove the door

by pulling upwards as shown in Figure 10. Remove the burner from its

place by pulling it to yourself as shown in Figure 11. As shown in Figure

12, remove the injector in the bearing with a socket wrench and insert

the injector suitable replacement.

In order to replace the burner, apply

the removal process reversely.

Figure 8

Figure 6

Figure 7

Figure 11

Figure 12

Figure 9

Figure 10
