15

Filter version

Should it not be possible to discharge cooking fumes and
vapour to the outside, the hood can be used in the

filter

version

, fitting an activated carbon filter and the deflector

F

on the support (bracket)

G

, fumes and vapours are recycled

through the top grille

H

 by means of an exhaust pipe

connected to the top air outlet

B

 and the connection ring

mounted on the deflector

F

 (exhaust pipe and pipe fixing

clamps not provided).

Attention! If the hood is not supplied with carbon filter,
then it must be ordered and mounted.

The models with no suction motor only operate in ducting
mode, and must be connected to an external suction device
(not supplied).
The connecting instructions are supplied with the peripheral
suction unit.

Installation

The minimum distance between the supporting surface for the
cooking equipment on the hob and the lowest part of the
range hood must be not less than 50cm from electric cookers
and 65cm from gas or mixed cookers.
If the instructions for installation for the gas hob specify a
greater distance, this must be adhered to.

  Electrical connection

The mains power supply must correspond to the rating
indicated on the plate situated inside the hood. If provided with
a plug connect the hood to a socket in compliance with current
regulations and positioned in an accessible area, after
installation. If it not fitted with a plug (direct mains connection)
or if the plug is not located in an accessible area, after
installation,  apply a double pole switch in accordance with
standards which assures the complete disconnection of the
mains under conditions relating to over-current category III, in
accordance with installation instructions.

Warning!

 Before re-connecting the hood circuit to the mains

supply and checking the efficient function, always check that
the mains cable is correctly assembled.
The hood is provided with a special power cable ; if the cable
is damaged, request a new one from Technical Service.

Mounting

Note:

 The hood may be installed both with and without a

chimney.

Before beginning installation:

•

Check that the product purchased is of a suitable size for
the chosen installation area.

•  To facilitate installation, remove the fat filters and the

other parts allowed and described here, dismantle and
mount it.

To remove see also the relative paragraphs.

•

Remove the active carbon (*) filter/s if supplied (see also
relative paragraph). This/these is/are to be mounted only
if you want lo use the hood in the filtering version.

•  Check (for transport reasons) that there is no other

supplied material inside the hood (e.g. packets with
screws (*), guarantees (*), etc.), eventually removing
them and keeping them.

•

If possible, disconnect and move freestanding or slide-in
range from cabinet opening to provide easier access to
rear wall/ceiling. Otherwise put a thick, protective
covering over countertop, cooktop or range to protect
from damage and debris. Select a flat surface for
assembling the unit. Cover that surface with a protective
covering and place all canopy hood parts and hardware
in it.

•  Disconnect the hood during electrical connection, by

turning the home mains switch off.

•

In addition check whether near the installation area of the
hood (in the area accessible also with the hood mounted)
an electric socket is available and it is possible to
connect a fumes discharge device to the outside (only
suction version).

•  Carry out all the masonry work necessary (e.g.

installation of an electric socket and/or a hole for the
passage of the discharge tube).


Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualified technician must
verify suitability of the materials in accordance with the type of
wall/ceiling. The wall/ceiling must be strong enough to take
the weight of the hood.

Do not tile, grout or silicone this

appliance to the wall. Surface mounting only.
Installation without flue

1.

  Use a pencil to mark the line representing the centre of

the appliance on the wall, as far as the ceiling. This will
make the installation process easier.

2.

  Position the drilling template on the wall: the vertical

centre line printed on the template should be aligned with
the centre line marked on the wall, and the lower edge of
the template should line up with the lower edge of the
cooker hood.

3.

  Rest the lower support bracket on the drilling template,

making sure it coincides with the sketched rectangle,
then mark the two outer holes and drill them.

Note:

 Always make the holes indicated on the template:

the 2 upper holes are used to position the hood, while the
lower holes (generally 1 central or several at the sides)
are used to fix it in place and secure it properly.

Remove the drilling template, insert the rawl plugs and fix
the cooker hood support bracket in place using 2 screws
measuring 5x45 mm.

4.

  Hang the cooker hood on the lower bracket.

5.

  Adjust the distance between the cooker hood and the

wall.

6.

  Adjust the horizontal position of the cooker hood.

7.

 Fix the cooker hood to the wall securely

(

COMPULSORY!!

).
