8

Instructions for use and maintenance

EN

(rigid – non stranded) conductor shall be used for the connection –

cable 3 x 2.5 mm² (cable 3 x 2.5 mm² for power > 3700W).

The electrical circuit supplying the appliance must have an in-built

device ensuring the splitting of all terminal poles under conditions of

super-voltage of category III.

To install the power supply wire to the appliances remove the plastic

cover.

Connect the power wires in compliance with the marks on the

terminals, as follows:

•

the phase - to mark A, A1, L or L1;

•

the neutral - to N (B or B1 or N1)

•

The safety wire must be obligatory connected to the screw joint

marked with  .
After the installation, put the plastic cover back in its place!

Explanations to Fig. 3:

TS - thermal switch; TR - thermal regulator; S - switch (for models

that have one); R - heater; IL - light indicator; F - flange.

VI.

RUST PROTECTION MAGNESIUM ANODE (FOR WATER

HEATERS WITH WATER TANKS COVERED BY GLASS-

CERAMICS COATING)

The magnesium anode protects the water tank’s inner surface from

corrosion.

The anode element is an element undergoing wear and tear and is

subject to periodic replacement.

In view of the long-term and accident free use of your water

heater, the manufacturer recommends periodic inspections of

the magnesium anode’s condition by a qualified technician and

replacement whenever required, and this could be performed during

the appliance’s technical preventive maintenance.

For replacements, please contact the authorized service stations!

VII.

OPERATION

Before switching on the appliance for first time, make sure that the

water heater is properly connected to the power supply network and

full with water.

1.

Models with BOOST control

1.1.

Control Elements

Fig. 2 where:

1 - Key of a power switch (on key models)

2 – luminous indicators

3 - Handle for thermoregulator (integrated with the key of the power

switch).

1.2.

Switching on the appliance .

The appliance is switched on by means of the appliance

incorporated in the installation described in subsection 3 of

paragraph V or by connecting the plug to the electrical socket (if the

model is with a cord with a plug).

The BOOST function is activated by the power switch button.
The power switch button of the appliance is embossed and is

marked



.

To  turn  on  the  BOOST  function,  press  the  button  until  it  stops  and

then  release  it.  The  button  remains  pressed  and  it  illuminates  in

red  color,  indicating  that  the  button  is  on  and  the  appliance  will  be

working at maximum power.

The maximum heating power is marked on the appliance type

plate.

The button illuminates continuously until the water in the appliance

gets warm. The button goes out when the set water temperature is

reached and the thermostat switches off the heater power.

To turn off the BOOST function, press the button until it stops, then

release it. The button must be stand out and the light signalization

goes out (if the appliance is in the heating mode), which means that

the BOOST function is off. The appliance remains in the minimal

power heater operation mode.

Attention

! The BOOST button illuminates only when the BOOST

function and the water heating mode are active. When the BOOST

function is activated and the set water temperature is reached, the BOOST

button is not illuminating. Indication for active BOOST function is the

pressed BOOST button.

BOOST

 “ON”

BOOST

 “OFF”

Control lights (indicators)

They illuminate in red color - the appliance is in the heating water

mode. (If the appliance is in BOOST mode, the BOOST button

illuminates in red color.)

They illuminate in blue color - the water in the appliance is heated

and the thermostat switches off the heater‘s power. (If the appliance

is in BOOST mode, the BOOST button extinguishes.)

Indicators do not illuminate in case of:

no electrical power is supplied to the appliance, or

the temperature protection of the appliance has been switched off -

see section 2 below.

When the BOOST function is activated, the unit operates at

maximum power to heat the water. The BOOST function is

recommended when you want the appliance to reach the set water

temperature for a short period of time.

Selecting a power level for heating the water:

Declared power

(marked on the nameplate

of the appliance)

Button BOOST off

Button BOOST on

1600 W

800 W

1600 W

2400 W

1200 W

2400 W

1.3.

Setting the temperature

This function allows you to select the desired temperature. To make

your choice, turn the handle on the panel by placing the marker in

the appropriate position (Fig. 2). To increase the temperature, turn

clockwise.

Place the thermostat knob in position for maximum temperature

(unless it is on this position constantly), for period of one day each

month - see

Annex-I (11)

 Maximum temperature of the thermostat. This

ensures higher hygiene of the used hot water.

•

Anti-freeze mode

Set the handle to the „MIN“ position according to figure 2. With this

setting, the appliance maintains a temperature that prevents the

water from freezing.

 The power supply of the appliance must be switched on.  The

safety valve and the pipeline from it to the appliance compulsory

must be secured against frost.

•

Energy-save mode - Position

e

At this mode, water temperature reaches up to approximately 60°С.

Heat losses are reduced in this way.

2.

Protection according to the temperature (valid for all

models).

The appliance is equipped with a special facility (thermal circuit-

breaker) for protection against over-heating of the water, which

is switching off the heater from the electricity network, when the

temperature reaches too high values.

When this device operates, it does not self-reset and the appliance

will not work. Please call an authorized service for solving the

problem.

VIII.

PERIODIC MAINTENANCE

Under normal use of the heater, under the influence of high

temperature, lime scale /the so-called lime scale layer/ is deposited

upon the heating element’s surface. This worsens the heat

exchange between the heating element and water. The heating

element’s surface temperature increases along /of boiling water/.

The thermoregulator begins to switch on and off more frequently. A

‘’deceptive” activation of the thermal protection is possible. Due to

these facts, the manufacturer recommends preventive maintenance

of your water heater every two years by an authorized service

center or service base. This protective maintenance must include

cleaning and inspection of the anode protector (for water heaters

with glass-ceramic coating), which shall be replace with a new one

if need arises.

In order to clean the appliances use a damp cloth. Do not clean with

abrasive or solvent content detergents. Do not pour water over the

appliance.

The manufacturer does not bare the responsibility for all

consequences caused by not obeying the instructions, given

hereby.

Instructions for protecting the environment

Old electric appliances contain precious materials and

thus should not be thrown together with the household

litter. We kindly ask you make your active contribution for

protecting the resources and the environment by handing

over the appliance in the authorized buy-back stations (if

such exist).
