1

2

4

3

The  rear  left  digit  indicates

  and  a

number indicating the type of menu. The
front  left  digit  indicates  a  number  which
depends on the parameters indicated in
the selection.

Select  the  digit  with    and  press  “8”  in
the power bar.

Select  the  front  left  digit  and  select  the
correct setting.
See the following table for the specifica-
tions:

Value on the

power bar

KW

Notes

0

7.4

Standard initial setting

1

4.5

2

3.5

3

2.8

Once  the  correct  value  has  been
entered,  confirm  by  touching  and  hold-
ing

.

10. HOB FUNCTIONS

Child lock

This function prevents accidental use of the appliance
To  enable:  if  a  pan  is  on  the  hob,  press  and  hold  the  corresponding  digit  for  3  seconds.  If  there  is

no pan on the hob, press and hold for 3 seconds one of the 5 digits (not visible) next to point

 on

the left side. Release and slide your finger from 0 to 9 along the power bar which displays the oper-

ating sequence. All the digits indicate

.

The operations described must be completed within 10 seconds.
To disable: press and hold for 3 seconds one of the 5 digits in the cooking areas. Release and slide

your finger from 9 to 0 along the power bar which displays the operating sequence.
The operations described must be completed within 10 seconds.

Lock

It  is  possible  to  lock  the  hob  functions  during  use,  e.g.  to  clean  the  hob.  The  function  is  enabled

even if the hob is switched off and on again.
If the electricity supply is cut, the function is disabled.
To enable: press

 and hold for 1 second.

To disable: press

.

Boost function

Every cooking area can be set to an additional power level for a maximum of 5 minutes.
To  enable:  select  one  of  the  4  cooking  areas  and  select  “P”  on  the  power  bar.  The  corresponding

digit indicates

.

To disable: select one of the other possible values on the power bar.

10
