23
English (Original instructions)
6. Replace the string trimmer head cover, aligning latches
with openings in the string trimmer head. Press cover
and string trimmer head together until both latches
snap securely into the openings.
7. Install the cutting line. Refer to "String replacement"
later in the manual for additional information.
WARNING
When using the ReelEasy™ string trimmer head, the
grass de
fl
ector must be attached from the blade guard.
See
fi
gure 24.
CONVERTING FROM GRASS TRIMMER TO
BRUSHCUTTER (SAW BLADE)
Removing the cutting attachment guard
See
fi
gure 8.
1. Stop the engine.
2. Remove the cutting attachment guard from the
mounting bracket.
Removing the ReelEasy™ string trimmer head
See
fi
gure 8.
1. Open the ReelEasy™ String Trimmer Head by
depressing the latches on each side. The contents of
the bump head are spring loaded, so keep your other
hand over the string head cover while depressing the
latches.
2. Remove the string head cover, bump knob, and line
spool.
3. Place the Allen wrench through the hole in the upper
fl
ange washer and the hole in the gear head. Using a
wrench, turn the hex bolt clockwise to remove.
4. Remove the washer and the string head housing from
the drive connector.
5. Using a combination wrench, turn the drive connector
clockwise to remove.
6. Remove the cupped washer from the gear shaft and
retain for later use.
NOTE:
Store the disassembled parts together for later
use.
Installing the saw blade guard
See
fi
gure 8.
1. Attach the saw blade guard to the mounting bracket
and align the screw holes on the saw blade guard to
the screws on the mounting bracket.
2. Tighten screws securely.
WARNING
When using the saw blade, the saw blade guard must
be attached to the mounting bracket.
Installing the saw blade
See
fi
gure 8.
To reduce the risk of injury, keep the blade protector on
the blades at all times. Remove the blade protector only
during cutting operations.
1. Centre the blade on the upper
fl
ange washer and make
sure the blade sits
fl
at. Install the cupped washer and
make sure it sits well into the gear shaft. Install blade
washer with the raised centre away from the blade.
2. Install the blade nut.
3. Place the Allen wrench through the hole in the
upper
fl
ange washer and the hole in the gear head.
Using the combination wrench, turn the blade nut
counterclockwise and tighten.
WARNING
Make sure the saw blade is in correct position. When
installing the saw blade, the silkscreen on the blade is
always on the top and towards the saw blade guard.
CONVERTING FROM BRUSHCUTTER (SAW BLADE)
TO GRASS TRIMMER
Removing the saw blade and saw blade guard
See
fi
gure 9.
1. Stop the engine.
2. Place the Allen wrench through the hole in the upper
fl
ange washer and the hole in the gear head. Turn the
blade nut clockwise to remove.
3. Remove the blade nut, cupped washer, saw blade,
and saw blade guard and retain for later use.
NOTE:
Store the disassembled parts together for later
use.
Installing the ReelEasy™ string trimmer head
See Figure 9.
1. Install the cupped washer. Install the drive connector
into the gear shaft. Place the Allen wrench through the
hole in upper
fl
ange washer and the hole in the gear
head. Using the combination wrench, turn the drive
connector counterclockwise and tighten securely.
2. Place the string head housing on the drive connector.
Make sure the housing is fully seated.
