39

■

TV/Video selector button

With this button you can select either source of input for the TV.

1. When the TV/VIDEO button

is first pressed, the TV/Video

menu appears and TV mode changes to VIDEO mode.

The screen is displayed in the last VIDEO mode.

2. Press the corresponding COLOUR button

to select one of

the input sources, as indicated in the diagram.

If you press any COLOUR button

during VIDEO mode, the

TV/Video menu will appears again.

Note: Each time the corresponding COLOUR button

is

pressed, AV1/S-VIDEO and FRONT / FRONT S-VIDEO change as
indicated below.

GREEN button

: AV1

S-VIDEO

BLUE button

: FRONT

FRONT S-VIDEO

The selected input will appear on the screen.

3. Press the MENU button

●

to remove the menu from the screen or press the TV/VIDEO button

and you will

exit the menu and VIDEO mode will change back to TV mode.

■

CLOCK button

f

Press the button to display the current time on the screen.

■

Headphone jack

The headphone jack is located behind the door.

How to open the door: Put the finger in the lower part of the door
and press upward.

Safety: In order to protect your ears, turn down the volume of the
headphones before connecting them.

1. Press the MENU button

●

twice to see the MAIN Menu.

2. Press the GREEN button

to see the Audio EFFECTS Menu.

3. Press the RED button

twice to see the HEADPHONES

LEVELS Menu.

4. Turn down the volume with the Cursor LEFT button

C

.

5. Insert the headphone plug all the way into the headphone jack as

indicated on the drawing.

6. Adjust the sound quality to your liking with the Cursor LEFT/RIGHT

buttons

C

/

I

.

7. Press the MENU button

●

to clear the on-screen display.

■

Sub-titles button

h

This set has a quick access function for teletext subtitles, so that they can be selected by the press of one button.
Simply press the

h

button on the remote control whilst in viewing mode (I.E. not teletext etc.) and subtitles will

automatically be selected and displayed on the screen.

To exit this mode, press

h

button again on the remote control.

NOTE: The subtitle page is 888 by default. Maybe it is possible that a broadcaster doesn’t use this page for subtitle.
Please check and choose in full-text-mode the correct page manually.

Other features

3.5 mm Ø Jack plug

Earphone or Headphone

Impedance 16~600

B

FRONT/SVIDEO

FRONT/SVIDEO

AV2

AV2

AV1/SVIDEO

AV1/SVIDEO

SCART

SCART

BLUE

RED

TV/Video Menu

GREEN

YELLOW

DOOR

BEHIND THE DOOR
