37

The following features are available for preset channels:

■

Fine-tuning

When a preset programme channel is not exactly tuned, you can fine-tune the channel in this mode.

1. Press the MENU button

●

twice to see the MAIN Menu.

2. Press the BLUE button

to see the TUNE Menu.

TUNE Menu

3. Press the Cursor UP/DOWN buttons

E

/

F

to select

«PROGRAMME» (red marked).

4. Press the Cursor LEFT/RIGHT buttons

C

/

I

(or 0 ~ 9 digit

buttons) to select the programme channel number you want to
tune.

5. Press the Cursor DOWN button

F

to select «FINE TUNE» (red

marked).

6. Press and hold the Cursor LEFT

C

or RIGHT

I

buttons, until

the best tuning position is found, for the best picture and sound.

After Fine-tuning the programme number will turn from white to
yellow.

7. Repeat the above procedure (3. ~ 6. steps) for other programme channels as required.

8. Press the MENU button

●

to clear the on-screen display.

■

Mode

This feature allows you to select TV, VCR or SKIP.

1. Press the MENU button

●

twice to see the MAIN Menu.

2. Press the BLUE button

to see the TUNE Menu.

TUNE Menu

3. Press the Cursor UP/DOWN buttons

E

/

F

to select

«PROGRAMME» (red marked).

4. Press the Cursor LEFT/RIGHT buttons

C

/

I

(or 0 ~ 9 digit

buttons) to select the programme channel number you want to set.

5. Press the Cursor DOWN button   to select «MODE» (red marked).

6. Press the Cursor LEFT/RIGHT buttons

C

/

I

to select:

“TV”, “VCR” or “SKIP”.

TV:

If the TV signal is weak the image can shake.

In this case put it in TV mode.

VCR:

In some cases, the upper part of the picture may be distorted when receiving signal from a VCR via RF

terminal on the TV set.

Selecting this option will help to reduce this effect.

SKIP:  Allows you to SKIP channels you do not want to view when using channels selector buttons

E

/

F

.

7. Repeat the above procedure (3. ~ 6. steps) for other programme channels as required.

8. Press the MENU button

●

to clear the on-screen display.

TUNE Menu

After preset has been performed

BLUE

MAIN Menu

I N S T A L L A T I O N

I N S T A L L A T I O N

E D I T

E D I T

PROGRAMME

AERIAL

B/G

21

TV

CHANNEL TYPE

SYSTEM

CHANNEL NUMBER

MODE

SEARCH

FINE TUNE

TUNE Menu

BLUE

MAIN Menu

I N S T A L L A T I O N

I N S T A L L A T I O N

E D I T

E D I T

PROGRAMME

AERIAL

B/G

21

TV

CHANNEL TYPE

SYSTEM

CHANNEL NUMBER

MODE

SEARCH

FINE TUNE
