21

With Double Window function, you can view two pictures (A and B) simultaneously by pressing the Double Window
button

l

. For example: the signal from the antenna terminal (picture A) and the signal from another device via one of

the external input terminals (picture B).

1.Press Double Window button

l

repeatedly to select a mode for viewing the two pictures:

«PIP» Mode (Picture In Picture): picture in picture.
«POP» Mode (Picture Out of Picture): picture out of picture.
«PAP» Mode (Picture Aside of Picture): picture aside of picture.

2. Press the YELLOW button

repeatedly to change the position of the windows.

Notes:
In «PIP» mode, only the secondary window changes position.
In «POP» mode, both windows change position.
In «PAP» mode the change position option is not available. In this mode, the main window is always on the left and the
secondary window on the right, regardless of the source of the signals being viewed..

3. Press the BLUE button

repeatedly to select the signal source of the secondary window.

4. Press the MENU button

●

to remove the menu from the window.

Sound reproduction in DOUBLE WINDOW mode:

●

The sound corresponding to the main window is reproduced via the loudspeakers and the volume can be adjusted

by pressing the volume UP / DOWN buttons

C

/

I

.

●

The sound corresponding to the secondary window is reproduced via the headphones and the volume can be

adjusted in the HEADPHONE LEVELS Menu (Page 26).

●

The loudspeaker / headphones

q

/

w

symbols appear alongside each window for a few seconds, indicating where

the sound of each window is reproduced. Press the numeric button

to view this information again later.

Exception: when both windows are showing pictures from two external inputs, the sound of the main window is
reproduced via both the loudspeakers and the headphones.

Double Window function

YELLOW

BLUE

BLUE

«PIP» Mode

Example of changing position in «PIP» mode

«POP» Mode

«PAP» Mode

(Main window)


B

(Secondary window)


B

(Secondary window)


(Main window)


(Main window)


(Secondary window)


S O U R C E

S O U R C E

P O S I T I O N

P O S I T I O N

YELLOW

BLUE

S O U R C E

S O U R C E

S O U R C E

S O U R C E

P O S I T I O N

P O S I T I O N

YELLOW

(Main window)


B

(Secondary window


B

(Secondary window

(Secondary window)




(Main window)


(Main window)


(Main window)


P O S I T I O N

P O S I T I O N

S O U R C E

S O U R C E

YELLOW

P O S I T I O N

P O S I T I O N

S O U R C E

S O U R C E

YELLOW

P O S I T I O N

P O S I T I O N

S O U R C E

S O U R C E

YELLOW

P O S I T I O N

P O S I T I O N

S O U R C E

S O U R C E
