16 ENGLISH

NOTICE:

Before using the powder filter, make

sure that prefilter and damper are always used

together.

 It is not allowed to install powder filter

solely.

Installing the paper pack

Optional accessory

WARNING:

When using the paper pack, also

use the prefilter together that is preinstalled on

the tool.

 Failure to use the prefilter together may

cause unusual noise and heat, resulting in a fire.

CAUTION:

Before using the paper pack, make

sure that powder filter, damper and prefilter are

always used together.

1.

Remove the rubber holder.

►

Fig.21:

1.

 Rubber holder

2.

  Extend the paper pack.

3.

Align the paper pack opening with the dust suction

opening of the cleaner.

4.

  Insert the cardboard of the paper pack onto the

holder so that it is positioned at the end beyond the

detent protrusion.

►

Fig.22:

1.

 Paper pack

2.

 Holder

Installing the polyethylene bag

Cleaner can also be used without polyethylene bag.

However, using polyethylene bag is easier to empty the

tank without letting your hands dirty.

Spread the polyethylene bag in the tank. Insert it

between the holder plate and the tank, and pull it to the

hose inlet.

►

Fig.23:

1.

 Holder plate

2.

 Polyethylene bag

Spread the bag around the top of the tank so that the

prefilter edge can catch and hold the bag securely.

►

Fig.24:

1.

 Prefilter

NOTE:

 A polyethylene bag available on the

market can be used. 0.04 mm or thicker one is

recommended.

NOTE:

 Too much dust will tear the bag easily, so

do not collect the dust more than the half of the bag

capacity.

Emptying the polyethylene bag

WARNING:

Always make sure that the

cleaner is switched off and the battery cartridge is

removed before emptying the polyethylene bag.

Failure to do so may cause an electric shock and

serious personal injury.

CAUTION:

Do not apply a great impact on the

tank.

 Applying a great impact may cause deformation

and damage to the parts.

CAUTION:

Empty the tank at least once a day

although this depends on picked-up dust volume

in the tank.

 Or, the suction force will weaken and the

motor may be broken.

CAUTION:

Do not grab the hook when empty-

ing the tank.

 Grabbing the hook may cause the hook

to break.

Unhook and lift up the tank cover.

Shake off the dust from the prefilter and then take the

polyethylene bag out of the tank.

►

Fig.25

NOTE:

 Take the polyethylene bag carefully out of the

tank so that the polyethylene bag cannot be caught

and torn by the protrusion inside the tank when emp-

tying it.

NOTE:

 Empty the polyethylene bag before it

becomes full. Too much dust in the tank may cause

the polyethylene bag to be torn.

Installing the tool box

1.

Release the lock of the battery cover, and open

the battery cover.

2.

Set the rails on the tool box along the grooves on

the housing.

3.

Close the battery cover and apply the lock.

►

Fig.26

The tool box is convenient for carrying batteries, pipe,

or cuffs.

►

Fig.27

Connecting the hose

NOTICE:

Never force the hose for bending or

stamp it. Never move the cleaner by a hose.

Forcing, stamping and pulling the hose may cause a

breakage or deformation of the hose.

NOTICE:

When picking up large wastes such as

planer carvings, concrete dusts or similar other

than small wastes, use the 38 mm inner diameter

hose (optional accessory).

 Using the 28 mm inner

diameter hose (optional accessory) may cause a

hose stuffing and damage.

Insert the hose onto the mounting port of the tank and

turn it clockwise until it locks.

►

Fig.28
