12 ENGLISH

WIRELESS ACTIVATION

FUNCTION

What you can do with the wireless

activation function

The wireless activation function enables clean and

comfortable operation. By connecting a supported tool

to the cleaner, you can run the cleaner automatically

along with the switch operation of the tool.

►

Fig.9

NOTICE:

Be sure to refer to the instruction man-

ual of the tool when using the cleaner with wire-

less activation function.

NOTICE:

Do not disassemble or tamper with the

wireless unit.

NOTICE:

Always close the lid of the wireless unit

in the tool when operating or storage.

NOTICE:

Do not remove the wireless unit from

the tool while the power is being supplied to the

tool.

 Doing so may cause a malfunction of the wire-

less unit.

NOTICE:

Do not press the wireless activation

button too hard and/or press the button with an

object with a sharp edge.

NOTE:

 Wireless activation needs Makita tools

equipped with the wireless unit.

NOTE:

 Prior to the initial use of the wireless activation

function with each tool, the tool registration is required.

Once the registration is finished with the tool, the

re-registration is not required unless it is cancelled.

NOTE:

 Before registration, be sure to the wireless

unit is properly inserted into the tool.

NOTE:

 One cleaner can register up to 10 tools. If

more than 10 tools are registered to the cleaner, the

tool registered earliest will be cancelled automatically.

NOTE:

 The position of the wireless activation button

varies depending on the tool.

NOTE:

 The cleaner also starts by pressing the power

button when the stand-by switch is set to "AUTO".

However the power button will not actuate when the

wireless activation function is used.

Tool registration for the cleaner

NOTE:

 A Makita tool supporting the wireless activa

-

tion function is required for the tool registration.

NOTE:

 Finish installing the wireless unit to the tool

before starting the tool registration.

NOTE:

 During the tool registration, do not pull the

switch trigger on the tool or turn on the power switch

on the cleaner.

NOTE:

 Refer to the instruction manual of the tool, too.

If you wish to activate the cleaner along with the

switch operation of the tool, finish the tool registration

beforehand.

1.

  Install the batteries to the cleaner and the tool.

2.

  Set the stand-by switch on the cleaner to "AUTO".

►

Fig.10:

1.

 Stand-by switch

3.

Press the wireless activation button on the cleaner

for 3 seconds until the wireless activation lamp blinks in

green. And then press the wireless activation button on

the tool in the same way.

►

Fig.11:

1.

 Wireless activation button

2.

 Wireless

activation lamp

If the cleaner and the tool are linked successfully, the

wireless activation lamps will light up in green for 2

seconds and start blinking in blue.

NOTE:

 The wireless activation lamps finish blinking

in green after 20 seconds elapsed. Press the wireless

activation button on the tool while the wireless acti-

vation lamp on the cleaner is blinking. If the wireless

activation lamp does not blink in green, push the wire-

less activation button briefly and hold it down again.

NOTE:

 When performing two or more tool registration

for the cleaner, finish the tool registration one by one.

Starting the wireless activation

function

NOTE:

 Finish the tool registration for the cleaner for

wireless activation.

NOTE:

 Always place the cleaner so that you can see

the status of the wireless activation lamp.

NOTE:

 Refer to the instruction manual of the tool, too.

After registering a tool to the cleaner, the cleaner will auto-

matically runs along with the switch operation of the tool.

1.

  Install the wireless unit to the tool.

2.

Connect the hose of the cleaner with the tool.

►

Fig.12

3.

  Set the stand-by switch on the cleaner to "AUTO".

►

Fig.13:

1.

 Stand-by switch

4.

Push the wireless activation button on the tool

briefly. The wireless activation lamp will blink in blue.

►

Fig.14:

1.

 Wireless activation button

2.

 Wireless

activation lamp

5.

  Pull the switch trigger of the tool. Check if the cleaner

runs while the switch trigger on the tool is being pulled.
To stop the wireless activation, push the wireless activa-

tion button on the tool, or set the stand-by switch on the

cleaner to "I" or "O".

NOTE:

 The wireless activation lamp on the tool will stop

blinking in blue when there is no operation for 2 hours. In

this case, set the stand-by switch on the cleaner to "AUTO"

and press the wireless activation button on the tool again.

NOTE:

 The cleaner starts/stops with a delay. There is a time

lag when the cleaner detects a switch operation of the tool.

NOTE:

 The transmission distance of the wireless unit may

vary depending on the location and surrounding circumstances.

NOTE:

 When two or more tools are registered to one

cleaner, the cleaner may start running even if you

don't pull the switch trigger because other user is

using the wireless activation function.
