CAMERA MENU Organization
E
ZOOM SPEED : Use [Left, Right] key in the ZOOM SPEED menu to set the speed
as follows.
ZOOM SPEED 1 : About 17Sec. from X 1 to X 12(Slowest)
ZOOM SPEED 2 : About 10Sec. from X 1 to X 12(Slow)
ZOOM SPEED 3 : About 6Sec. from X 1 to X 12(Fast)
ZOOM SPEED 4 : About 3Sec. from X 1 to X 12(Fastest)
D-ZOOM : Sets up the Digital Zoom magnification ratio up to x10.
RS-485 : Sets up RS-485 Communication Protocol, Address, and Baud Rate.
SYSTEM INFO : You can confirm settings related to the RS-485 communication,
product serial number, and the software version.
PRESS THE
ENTER
BUTTON.
(OTHER SET)
LANGUAGE ENGLISH
ZOOM SPEED
1
DIGITAL ZOOM OFF
RS-485 ...
SYSTEM INFO
...
V-SYNC INT
DISPLAY ZOOM
ON
RET
(RS-485)
PROTOCOL
SAMSUNG
BAUD RATE
9600
ADDRESS 0
RET
V-SYNC : INT shall be selected to use internal synchronization. LINE... is used to
synchronize several camera phases for the multi camera operation by using
an external signal(AC signal). As there may be a slight deviation between
sets, adjusts PHASE to overcome this handicap. When you use AC power
source, V-SYNC is available. Select LINE... and press [ENTER] and the
PHASE control submenu will appear. The PHASE control ranges
from -106H to +106H as for NTSC and from -138H to +138H as for PAL.
PRESS THE
ENTER
BUTTON.
(OTHER SET)
LANGUAGE ENGLISH
ZOOM SPEED
1
DIGITAL ZOOM OFF
RS-485 ...
SYSTEM INFO
...
V-SYNC INT
DISPLAY ZOOM
ON
RET
(SYSTEM INFO)
ROM VER
0.207
EEP VER
0.208
PROTOCOL
SAMSUNG
ADDRESS 0
TYPE RS-485,
HALF
BAUD RATE
9600
SERIAL NO
000000000000000
RET
PRESS THE
ENTER
BUTTON.
(OTHER SET)
LANGUAGE ENGLISH
ZOOM SPEED
1
DIGITAL ZOOM
OFF
RS-485
...
SYSTEM INFO
...
V-SYNC
LINE...
DISPLAY ZOOM
ON
RET
(LINE LOCK)
PHASE (-308)I--------
RET
❖
When a DC power is supplied, V-SYNC menu will be displayed as --- and
you cannot make any settings.
