36
37
E
E
The FOCUS MODE menu performs MF(Manual Focus), and ONEAF(One Auto Focus).
- MF : You can manually adjust the focus.
- ONEAF : Focusing will take about 5 seconds in ONEAF mode. When turned off,
it is same to the MF mode.
FOCUS MODE
CAMERA ID
ON...
IRIS
ALC...
SHUTTER
OFF
AGC
LOW
WHITE BAL
ATW1
FOCUS MODE
ONEAF
ALARM SET
...
COLOR/BW
COLOR...
PRIVACY
ON...
SPECIAL
...
PRESET
...
EXIT
QUIT
(MANU)
PRESET
3200K
RET
The Alarm Set feature consists of one Alarm In and one Alarm Out, which detects an
Alarm In signal from an external sensor and moves to the position pre-defined by the
Position Set for the alarming process. Then, it returns to the original position. And it also
transfers the Alarm Out signal to external devices. When as much time as the Dwell Time
in that position has passed, it will go back to the original position. If no particular position
is defined by the Position Set, it will move to the maximum TELE.
MOTION DET detects any motion. Set up this function during no human movement to
detect break-in. Once detected, an ALARM signal will be given for 5 seconds. As MOTION
DET detects any motion, so it can set up the motion detection sensitivity. Select ON... and
press [ENTER] and the MOTION DET submenu screen will appear.
If you select ON and press the ENTER button, the MOTION DET screen will come up. You
can set the AREA to which the Motion Detection function will be applied to either PRESET
or USER. If you set the AREA option to PRESET, the Motion Detection function will be
applied to the areas preset as factory defaults. If you set the AREA option to USER and
press the ENTER button, you can change the area size and position and select the area
where you want to apply the Motion Detection function.You can specify the size of the area
by using the UP, DOWN, LEFT, and RIGHT buttons. If the area is not flashing, press the
ENTER button. When the area starts flashing, use the UP, DOWN, LEFT and RIGHT
buttons to specify the location of the area. Use the ENTER button and the UP, DOWN,
LEFT, and RIGHT buttons to specify the size of the area and to position the area. Press
the ENTER button again to exit the AREA setting menu. You can use the SENSITIVITY
option to set the motion detection sensitivity. The higher the setting, the more sensitive the
motion detection.
ALARM SET
PRESS THE
ENTER
BUTTON.
CAMERA ID
ON...
IRIS
ALC...
SHUTTER
OFF
AGC
LOW
WHITE BAL
ATW1
FOCUS MODE
ONEAF
ALARM SET
...
COLOR/BW
COLOR...
PRIVACY
ON...
SPECIAL
...
PRESET
...
EXIT
QUIT
(ALARM SET)
ALARM IN
OFF
MOTION DET
OFF
POSITION SET
...
ZOOM DWELL TIME 5S
ALARM OUT
ALL
RET
CAMERA MENU Organization
