XClarity Controller Advanced Upgrade adds the following functionality to the Standard features:
Remotely viewing video with the following graphics resolutions:
Up to 1600x1200 with up to 23 bits per pixel; or
Up to 1920x1200 with up to 15 bits per pixel
Remotely accessing the server using the keyboard and mouse from a remote client
Remotely deploying an operating system
Syslog alerting
Redirecting serial console via SSH
Displaying graphics for real-time and historical power usage data and temperature
XClarity Controller Enterprise Upgrade adds the following functionality to the Advanced features:
Capping power usage
Mapping the ISO and image files located on the local client as virtual drives for use by the server
Mounting the remote ISO and image files via HTTPS, SFTP, CIFS, and NFS
Collaborating across up to six users of the virtual console
Controlling quality and bandwidth usage
The XClarity Controller provides remote server management through industry-standard interfaces:
Intelligent Platform Management Interface (IPMI) Version 2.0
Simple Network Management Protocol (SNMP) Version 3
Common Information Model (CIM)
Data Center Manageability Interface (DCMI) Version 1.5
Redfish REpresentational State Transfer (REST) API
Web browser with HTML5 support
Command-line interface
Virtual Operator Panel with XClarity Mobile App via the front USB port with XClarity Controller access
Virtual Operator Panel provides quick access to system status, firmware, network, health, and alerts information.
With proper authentication, it also allows to configure systems management and network settings and to control
system power (Power on, Power off, Restart). The Virtual Operator Panel can be accessed from the XClarity
Mobile App running on the Android or iOS mobile device that is connected to the front USB port with XClarity
Controller access (See
).
Note:
Depending on the system settings, the front USB port can be assigned to XClarity Controller for
management functions, or to the system as a regular USB 2.0 port, or switched between two functions by using
the system ID button.
IPMI via the Ethernet port (IPMI over LAN) is supported, however it is disabled by default. For CTO orders you
can specify whether you want to the feature enabled or disabled in the factory, using the feature codes listed in
the following table.
Table 40. IPMI-over-LAN settings
Part number
Feature code
Description
CTO only
B7XZ
Disable IPMI-over-LAN (default)
CTO only
B7Y0
Enable IPMI-over-LAN
Lenovo ThinkSystem SR550 Server (Xeon SP Gen 2)
39
