12

English

CAUTION:

When using the tool as a spotlight, be sure

it is secured on a stable surface where it will not cause a
tripping or falling hazard.

CAUTION:

Remove all accessories from the chuck before

using the drill as a spotlight. Personal injury or property
damage could result.

Low Battery Warning

When in spotlight mode and the battery is nearing complete
discharge, the spotlight will flash twice and then dim. After two
minutes, the battery will be completely discharged and the
drill will immediately shut down. At this point, replace with a
charged battery.

WARNING:

 To reduce the risk of injury, always have a

back-up battery or secondary lighting available if the
situation warrants it.

Belt Hook and Magnetic Bit Holder (Fig. A)

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.

WARNING: To reduce the risk of serious personal
injury, DO NOT

suspend tool overhead or suspend

objects from the belt hook.

ONLY

 hang tool’s belt hook

from a work belt.

WARNING: To reduce the risk of serious personal
injury,

ensure the screw holding the belt hook is secure.

CAUTION: To reduce the risk of personal injury or
damage, DO NOT use the belt hook to hang the drill
while using as a spotlight.

iMPORTAnT:

When attaching or replacing the belt hook or

magnetic bit holder, use only the screw

 11

 that is provided. Be

sure to securely tighten the screw.
The belt hook

 10

 and magnetic bit holder

 12

 can be be

attached to either side of the tool using only the screw

 11

provided, to accommodate left- or right- handed users. If the
hook or magnetic bit holder is not desired at all, it can be
removed from the tool.
To move belt hook or magnetic bit holder, remove the screw

 11

 that holds it in place then reassemble on the opposite side.

Be sure to securely tighten the screw.

OPERATION
Instructions for Use

WARNING:

Always observe the safety instructions and

applicable regulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories.

An accidental

start-up can cause injury.

Proper Hand Position (Fig. I)

WARNING:

To reduce the risk of serious personal injury,

ALWAYS

 use proper hand position as shown in figure I.

WARNING:

 To reduce the risk of serious personal

injury,

ALWAYS

 hold securely in anticipation of a

sudden reaction.

Proper hand position requires one hand on the main handle

 18

, with the other hand on the side handle

 7

.

Drill Operation (Fig. D)

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories.

WARNING: TO REDUCE THE RISK OF PERSONAL
INJURY, ALWAYS

 ensure workpiece is anchored or

clamped firmly. If drilling thin material, use a wood “back-
up” block to prevent damage to the material.

1.  Select the desired speed/torque range using the gear shifter

to match the speed and torque to the planned operation.
Set the torque adjustment collar

 5

 to the drill symbol.

2.  For Wood, use twist bits, spade bits, power auger bits or

hole saws. For Metal, use high-speed steel twist drill bits
or hole saws. Use a cutting lubricant when drilling metals.
The exceptions are cast iron and brass which should be
drilled dry.

3.  Always apply pressure in a straight line with the bit. Use

enough pressure to keep the drill bit biting, but do not push
hard enough to stall the motor or deflect the bit.

4.  Hold tool firmly with both hands to control the twisting

action of the drill.

5.

iF DRill sTAlls,

 it is usually because it is being

overloaded.

RElEAsE TRiggER iMMEDiATElY,

 remove

drill bit from work, and determine cause of stalling.

DO nOT

CliCK TRiggER OFF AnD On in An ATTEMPT TO sTART
A sTAllED DRill – This CAn DAMAgE ThE DRill.

6.  Keep the motor running when pulling the bit back out of a

drilled hole. This will help prevent jamming.

Screwdriver Operation (Fig. C)

1.  Select the desired speed/torque range using the three-

speed gear shifter

 6

 on the top of the tool. If using the

torque adjustment collar

 5

, initially set the three-speed

gear shifter to speed 2 or 3. This ensures effective control
over the fastener allowing the screw to be seated correctly
and set to specification. Speed 1 will provide the same
clutching torque as speeds 2 and 3. However, for optimum
performance of the electronic clutch, speeds 2 and 3
are preferred.

nOTE:

Use the lowest torque setting (1) first and increase

the number through to the highest setting (11) to seat the
fastener at the desired depth. The lower the number, the
lower the torque output.

2.  Reset the torque adjustment collar

 5

 to the appropriate

number setting for the torque desired. Make a few practice
runs in scrap or unseen areas to determine the proper
position of the torque adjustment collar.

nOTE:

The torque adjustment collar may be set to any number

at any time.
