14

 | English

1 609 929 W83 | (9.11.10)

Bosch Power Tools

f

Never use the machine with a damaged
cable. Do not touch the damaged cable and
pull the mains plug when the cable is dam-
aged while working.

Damaged cables

increase the risk of an electric shock.

f

Check the cable regularly and have a dam-
aged cable repaired only through an author-
ised customer service agent for Bosch power
tools. Replace damaged extension cables.

This will ensure that the safety of the power
tool is maintained.

f

Wear non-skid shoes.

This prevents injuries

that can occur from slipping on smooth sur-
faces.

f

Use only original Bosch accessories.

f

The safety and operating instructions for
the drill stand and the accessories being
used are to be strictly observed!

f

Never leave the machine before it has come
to a complete stop.

Cutting tools that are

still running can cause injuries.

f

Connect the machine to a mains supply with
proper earthing connection.

Socket outlet

and extension cable must be equipped with
an operative protective conductor.

f

Products sold in GB only

: Your product is fit-

ted with an BS 1363/A approved electric plug
with internal fuse (ASTA approved to
BS 1362).
If the plug is not suitable for your socket out-
lets, it should be cut off and an appropriate
plug fitted in its place by an authorised cus-
tomer service agent. The replacement plug
should have the same fuse rating as the origi-
nal plug.
The severed plug must be disposed of to
avoid a possible shock hazard and should nev-
er be inserted into a mains socket elsewhere.

Products sold in AUS and NZ only

: Use a re-

sidual current device (RCD) with a rated re-
sidual current of 30 mA or less.

Functional Description

Read all safety warnings and all
instructions.

Failure to follow the

warnings and instructions may
result in electric shock, fire and/or
serious injury.

While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.

Intended Use

In conjunction with wet-drilling diamond core
bits and a water supply, the machine is intended
for wet drilling in mineral materials such as con-
crete and reinforced concrete. It is not suitable
for overhead drilling. The machine may only be
used in conjunction with the S 500 A diamond-
drill stand. The machine can be used in combi-
nation with an extraction device (water collec-
tion ring and all-purpose vac).

Product Features

The numbering of the product features refers to
the illustration of the machine on the graphics
page.

1

S 500 A diamond-drill stand *

2

Residual current device (RCD)

3

Water outlet connector

4

Gear selector

5

Feed handle  (S 500 A)

6

Water collection ring *

7

Core bit *

8

Sliding ring *

9

Drill spindle

10

Water-flow indicator

11

Water cock

12

Control indicator

13

On/Off switch

14

Insulated gripping surfaces

* Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
