18
| English
a power failure or when the mains plug is pulled.
This
prevents uncontrolled restarting.
u
Secure the workpiece.
A workpiece clamped with
clamping devices or in a vice is held more secure than by
hand.
Products sold in GB only:
Your product is fitted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an au-
thorised customer service agent. The replacement plug
should have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains
socket elsewhere.
Product Description and
Specifications
Read all the safety and general instructions.
Failure to observe the safety and general in-
structions may result in electric shock, fire
and/or serious injury.
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended use
The power tool is intended for cutting, roughing and brush-
ing metal and stone materials without the use of water.
A special protective guard for cutting must be used when
cutting bonded abrasives.
Sufficient dust extraction must be provided when cutting
stone.
With approved abrasive tools, the power tool can be used for
sanding with sanding discs.
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Spindle lock button
(2)
On/off switch
(3)
Speed preselection thumbwheel (GWS 9-115 S/
GWS 9-125 S)
(4)
Auxiliary handle (insulated gripping surface)
(5)
Combination wrench for grinding spindle M 14
a)
(6)
Grinding spindle
(7)
Protective guard for grinding
(8)
Locking screw for protective guard
(9)
Mounting flange with O‑ring
(10)
Grinding disc
a)
(11)
Clamping nut
(12)
Quick-clamping nut
a)
(13)
Carbide grinding head
a)
(14)
Protective guard for cutting
a)
(15)
Cutting disc
a)
(16)
Hand guard
a)
(17)
Rubber sanding pad
a)
(18)
Abrasive disc
a)
(19)
Round nut
a)
(20)
Cup brush
a)
(21)
Handle (insulated gripping surface)
a)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
Technical Data
Angle grinder
GWS 9-115
GWS 9-125
GWS 9-115 S
GWS 9-125 S
Article number
3 601 C96 0..
3 601 C96 0..
3 601 C96 1..
3 601 C96 1..
Rated power input
W
900
900
900
900
Power output
W
450
450
450
450
Rated speed
min
-1
11,000
11,000
11,000
11,000
Speed adjustment range
min
-1
–
–
2800–11,000
2800–11,000
Max. grinding disc diameter
mm
115
125
115
125
Grinding spindle thread
M 14
M 14
M 14
M 14
Max. thread length of grinding
spindle
mm
22
22
22
22
Speed preselection
–
–
●
●
Restart protection
–
–
●
●
Weight according to EPTA-Procedure 01:2014
– With low-vibration auxiliary
handle
kg
2.0
2.0
2.0
2.0
1 609 92A 56A | (12.02.2021)
Bosch Power Tools
