 Remove the reusable or paper dustbag (see chapter ‘Replacement’). (Fig. 20)

  5

 Insert the float unit into the container by its handle. (Fig. 21)

Note:The float unit only fits into the appliance in one way.

  6

 Turn the motor unit upside down. (Fig. 12)

  7

 Insert the diffuser into the motor unit. (Fig. 22)

  8

 Put the motor unit back onto the appliance and close the clamps (‘click’). (Fig. 18)

  9

 Remove the Micro Filter (specific types only). (Fig. 23)

Note:If the Micro Filter is exposed to excessive air humidity, it loses its electrostatic properties.

Now the appliance is ready for vacuuming liquids.

Preparing for shampooing

To shampoo floors, you need the float unit, the diffuser, the shampoo reser voir (filled with shampoo

and water), the double-injection nozzle and the shampoo trigger.

  1

 Follow steps 1 to 9 in ‘Preparing for vacuuming liquids’.

 Fill the shampoo reservoir with cold water. (Fig. 24)

 Add one measuring cup of cleaning liquid to the full reservoir. (Fig. 25)

 Attach the shampoo reservoir to the appliance. (Fig. 26)

  5

 Insert the short shampoo hose to the connector on the vacuum cleaner (1) and turn it

anticlockwise (2). (Fig. 27)

  6

 Connect the long shampoo hose to the shampoo trigger. (Fig. 28)

  7

 Fasten the shampoo trigger to the handgrip of the suction hose. (Fig. 29)

  8

 Firmly insert the end of the long shampoo hose into the connector on the vacuum cleaner

(‘click’). (Fig. 30)

To release the shampoo hose, push the ring towards the appliance. (Fig. 31)

  9

 Fasten the long shampoo hose to the suction hose and suction tube with the shampoo hose

clips. (Fig. 32)

 10

 Attach the double-injection nozzle. (Fig. 6)

The appliance is now ready for shampooing soft floors, such as carpets and rugs.

Using the appliance

  1

 Pull the mains cord out of the appliance and insert the mains plug into the wall socket.

(Fig. 33)

 Switch on the appliance. (Fig. 34)

Dry use

Convertible nozzle

You can use the convertible nozzle to vacuum hard and soft floors: (Fig. 35)

With the brush strip folded out, you can use the nozzle to clean hard floors (wooden, ceramic,

stone and synthetic floors)

With the brush strip folded in, you can use the nozzle to clean soft floors (carpets and rugs)

,

,

-

-

English

11
