38

EN

USING YOUR DYSON APPLIANCE

PLEASE READ THE ‘IMPORTANT SAFET Y INSTRUCTIONS’ IN THIS DYSON

OPER ATING M ANUAL BEFORE PROCEEDING.

OPER ATION

•

Do not use outdoors or on wet surfaces or to vacuum water or other liquids –

electric shock could occur.

•

Ensure the appliance remains upright in use and in storage. Dirt and debris may

be released if it is turned upside down.

•

Do not operate while checking for blockages.

•

For domestic indoor and car use only. Do not use it whilst the car is in motion or

while driving.

•

To operate the Max mode, locate the switch on the top of the appliance. Slide

the switch to the Max mode position.

•

To switch off Max mode, slide the switch back to the Powerful Suction

mode position.

•

This product has carbon fibre brushes. Take care if coming into contact with

them, as they may cause minor skin irritation. Wash your hands after handling

the brushes.

DIAGNOSTICS – LIGHTS DURING CHARGING

DIAGNOSTICS – DURING USE

DOCKING STATION INSTALLATION

•

Use appropriate mounting hardware for your wall type and ensure that the

docking station is mounted securely. Ensure no pipe work (gas, water, air) or

electrical cables, wires or ductwork are located directly behind the mounting

area. The docking station must be mounted in accordance with regulations

and applicable codes/standards (state and local laws may apply). Dyson

recommends the use of protective clothing, eyeware and materials when

installing the docking station.

CARPETS OR HARD FLOORS

•

Before vacuuming your flooring, rugs and carpets, check the manufacturer’s

recommended cleaning instructions.

•

The brush bar on the appliance can damage certain carpet types and floors.

Some carpets will fuzz if a rotating brush bar is used when vacuuming. If this

happens, we recommend vacuuming without the motorised floor tool and

consulting with your flooring manufacturer.

•

Before vacuuming highly polished floors, such as wood or lino, first check that

the underside of the floor tool and its brushes are free from foreign objects that

could cause marking.

LOOKING AFTER YOUR DYSON APPLIANCE

•

Do not carry out any maintenance or repair work other than that shown in this

Dyson Operating Manual, or advised by the Dyson Helpline.

•

Only use parts recommended by Dyson. If you do not this could invalidate

your guarantee.

•

Store the appliance indoors. Do not use or store it below 3°C (37.4°F). Ensure

the appliance is at room temperature before operating.

•

Clean the appliance only with a dry cloth. Do not use any lubricants, cleaning

agents, polishes or air fresheners on any part of the appliance.

VACUUMING

•

Do not use without the clear bin and filters in place.

•

Fine dirt such as flour should only be vacuumed in very small amounts.

•

Do not use the appliance to pick up sharp hard objects, small toys, pins, paper

clips, etc. They may damage the appliance.

•

When vacuuming, certain carpets may generate small static charges in the

clear bin or wand. These are harmless and are not associated with the mains

electricity supply. To minimise any effect from this, do not put your hand or

insert any object into the clear bin unless you have first emptied it. Clean the

clear bin with a damp cloth only. (See ‘Cleaning the clear bin’.)

•

Use extra care when cleaning on stairs.

•

Do not rest the appliance on chairs, tables, etc.

•

Do not press down on the nozzle with excessive force when using the appliance

as this may cause damage.

•

Do not leave the cleaner head in one place on delicate floors.

•

On waxed floors the movement of the cleaner head may create an uneven

lustre. If this happens, wipe with a damp cloth, polish the area with wax, and

wait for it to dry.

EMPTYING THE CLEAR BIN

•

Empty as soon as the dirt reaches the level of the M A X mark – do not overfill.

•

Ensure the appliance is disconnected from the charger before emptying the

clear bin. Be careful not to pull the 'ON' trigger.

•

To make emptying the clear bin easier, it is advisable to remove the wand and

floor tool.

•

To minimise dust/allergen contact when emptying, encase the clear bin tightly in

a plastic bag and empty.

•

To release the dirt, hold the appliance by the handle, pull the red lever back and

lift upwards to release the cyclone. Continue until the bin base automatically

opens and releases the dirt.

•

Remove the clear bin carefully from the bag.

•

Seal the bag tightly, dispose as normal.

•

To close, push the cyclone downwards until it is in the normal position and

manually close the base of the bin – the base will click when it is securely

in place.

CLEANING THE CLEAR BIN

•

Ensure the appliance is disconnected from the charger before removing the

clear bin. Be careful not to pull the ‘ON’ trigger.

•

Remove the wand and floor tool.

•

To remove the cyclone, hold the appliance by the handle, pull the red lever

towards you and lift upwards until the bin opens, then push in the red button

located behind the cyclone and lift the cyclone out.

•

To detach the clear bin from the appliance, pull back on the red catch located

at the base, slide the clear bin down and carefully remove forwards from the

main body.

•

Clean the clear bin with a damp cloth only.

•

Do not use detergents, polishes or air fresheners to clean the clear bin.

•

Do not put the clear bin in a dishwasher.

•

Ensure the clear bin is completely dry before replacing.

•

To replace the clear bin, align the tabs on the clear bin with the grooves on the

main body and slide upwards into place until the catch clicks.

•

Slide the cyclone into the grooves of the main body and push downwards until

it is in its normal position and manually close the base of the bin – the base will

click when it is securely in place.

WASHABLE PARTS

Your appliance has washable parts, which require regular cleaning. Follow the

instructions below.

WASHING THE BRUSH BARS

•

Your appliance has two washable brush bars, check and wash these regularly

according to the following instructions to maintain performance.

•

Ensure the appliance is disconnected from the charger before removing the

brush bar. Be careful not to pull the ‘ON’ trigger.
TO REMOVE, WASH AND REPL ACE BRUSH BARS:

•

Please refer to the ‘Washing the brush bars’ illustrations alongside the

instructions below.

•

Turn the cleaner head upside down so the underside of the cleaner head is

facing you. Use a coin to turn the fastener one quarter anti-clockwise to the

unlocked position.

•

Rotate the end cap to the open position. Gently slide the large brush bar away

from the cleaner head.

•

Remove the end cap from the large brush bar.

•

Lift out the small brush bar from the octagonal end and pull away from the

cleaner head.

•

Hold the brush bars under running water and gently rub to remove any lint

or dirt.

•

Stand both brush bars upright. Ensure the large brush bar is stood upright as

shown. Leave to dry completely for a minimum of 24 hours.

•

Before replacing, check that the brush bars are completely dry. Refit the small

brush bar before the large one. Insert the round end of the small brush bar into

place. Push down the octagonal end until it clicks into place.

Charging, low charge.

Charging, nearly full.

Charger fault – call the Dyson Helpline.

Charging, medium charge.

Fully charged.

Battery fault – call the Dyson Helpline.

High level of charge.

Low level of charge.

Battery fault – call the Dyson

Helpline.

Medium level of charge.

Empty, needs recharging.

Main body fault – call the

Dyson Helpine.
