18 ENGLISH

Hammer drilling operation

CAUTION:

 There is tremendous and sudden

twisting force exerted on the tool/drill bit at the time of

hole break-through, when the hole becomes clogged

with chips and particles, or when striking reinforcing

rods embedded in the concrete.

Always use the side

grip (auxiliary handle) and firmly hold the tool by

both side grip and switch handle during opera

-

tions.

 Failure to do so may result in the loss of control

of the tool and potentially severe injury.

Set the action mode changing knob to the

 symbol.

Position the drill bit at the desired location for the hole,

then pull the switch trigger. Do not force the tool. Light

pressure gives best results. Keep the tool in position

and prevent it from slipping away from the hole.
Do not apply more pressure when the hole becomes

clogged with chips or particles. Instead, run the tool at

an idle, then remove the drill bit partially from the hole.

By repeating this several times, the hole will be cleaned

out and normal drilling may be resumed.

NOTE:

 Eccentricity in the drill bit rotation may occur

while operating the tool with no load. The tool auto-

matically centers itself during operation. This does not

affect the drilling precision.

Chipping/Scaling/Demolition

Set the action mode changing knob to the  symbol.

Hold the tool firmly with both hands. Turn the tool on

and apply slight pressure on the tool so that the tool will

not bounce around, uncontrolled.

Pressing very hard on the tool will not increase the

efficiency.

►

Fig.32

Drilling in wood or metal

CAUTION:

Hold the tool firmly and exert care

when the drill bit begins to break through the

workpiece.

 There is a tremendous force exerted on

the tool/drill bit at the time of hole break through.

CAUTION:

A stuck drill bit can be removed

simply by setting the reversing switch to reverse

rotation in order to back out. However, the tool

may back out abruptly if you do not hold it firmly.

CAUTION:

Always secure workpieces in a

vise or similar hold-down device.

NOTICE:

Never use “rotation with hammering”

when the drill chuck is installed on the tool.

 The

drill chuck may be damaged.

Also, the drill chuck will come off when reversing the

tool.

NOTICE:

Pressing excessively on the tool will

not speed up the drilling.

 In fact, this excessive

pressure will only serve to damage the tip of your drill

bit, decrease the tool performance and shorten the

service life of the tool.

Set the action mode changing knob to the   symbol.

For DHR280/DHR282

Optional accessory

Attach the chuck adapter to a keyless drill chuck to

which 1/2"-20 size screw can be installed, and then

install them to the tool. When installing it, refer to the

section “Installing or removing drill bit”.

►

Fig.33:

1.

 Keyless drill chuck

2.

 Chuck adapter

For DHR281/DHR283

Use the quick change drill chuck as standard equip-

ment. When installing it, refer to "changing the quick

change chuck for SDS-plus".

Hold the ring and turn the sleeve counterclockwise to

open the chuck jaws. Place the bit in the chuck as far as

it will go. Hold the ring firmly and turn the sleeve clock

-

wise to tighten the chuck.

►

Fig.34:

1.

 Sleeve

2.

 Ring

To remove the bit, hold the ring and turn the sleeve

counterclockwise.

Diamond core drilling

NOTICE:

If performing diamond core drilling

operations using “rotation with hammering”

action, the diamond core bit may be damaged.

When performing diamond core drilling operations,
always set the change lever to the   position to use

"rotation only" action.

Beating dust on the filter

Optional accessory

CAUTION:

Do not turn the dial on the dust

case while the dust case is removed from the

dust collection system.

 Doing so may cause dust

inhalation.

CAUTION:

Always switch off the tool when

turning the dial on the dust case.

 Turning the dial

while the tool is running may result in the loss of

control of the tool.

By beating the dust on the filter inside the dust case,

you can keep the vacuum efficiency and also reduce

the number of times to dispose of the dust.

Turn the dial on the dust case three times after col-

lecting every 50,000 mm

3

 of dust or when you feel the

vacuum performance declined.

NOTE:

 50,000 mm

3

 of dust equivalents to drilling 10

holes of ø10 mm and 65 mm depth (14 holes of ø3/8″

and 2″ depth).

►

Fig.35:

1.

 Dust case

2.

 Dial
