16 ENGLISH

Hook

CAUTION:

Never hook the tool at high loca

-

tion or on potentially unstable surface.

►

Fig.12:

1.

 Hook

The hook is convenient for temporarily hanging the tool.

To use the hook, simply lift up hook until it snaps into

the open position. When not in use, always lower hook

until it snaps into the closed position.

Adjusting the nozzle position of the

dust collection system

Optional accessory

Push in the guide while pushing up the guide adjust

-

ment button, and then release the button at the desired

position.

►

Fig.13:

1.

 Guide

2.

 Guide adjustment button

NOTE:

 Before adjusting the nozzle position, release

the nozzle forward completely by pushing up the

guide adjustment button.

If a long drill bit is installed, extend the guide by pushing

up the extension button.

►

Fig.14:

1.

 Extension button

Adjusting the drilling depth of the

dust collection system

Optional accessory

Slide the depth adjustment button to the desired posi

-

tion while pushing it up. The distance (A) is the drilling

depth.

►

Fig.15:

1.

 Depth adjustment button

Torque limiter

NOTICE:

As soon as the torque limiter actuates,

switch off the tool immediately.

 This will help pre-

vent premature wear of the tool.

NOTICE:

Drill bits such as hole saw, which tend

to pinch or catch easily in the hole, are not appro

-

priate for this tool.

 This is because they will cause

the torque limiter to actuate too frequently.

The torque limiter will actuate when a certain torque

level is reached. The motor will disengage from the

output shaft. When this happens, the drill bit will stop

turning.

Electronic function

The tool is equipped with the electronic functions for

easy operation.
•

Constant speed control

The speed control function provides the constant

rotation speed regardless of load conditions.

•

Active Feedback sensing Technology (For

DHR282/DHR283)

If the tool is swung at the predetermined accelera-

tion during operation, the motor is forcibly stopped

to reduce the burden on the wrist.

NOTE:

 This function does not work if the acceleration

does not reach the predetermined one when the tool

is swung.

NOTE:

 If the bit is swung at the predetermined

acceleration during chipping, scaling, or demolishing,

the motor is forcibly stopped. In this case, release

the switch trigger, and then pull the switch trigger to

restart the tool.

ASSEMBLY

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before carrying out any work on the tool.

Side grip (auxiliary handle)

CAUTION:

Always use the side grip to ensure

safe operation.

CAUTION:

After installing or adjusting the

side grip, make sure that the side grip is firmly

secured.

To install the side grip, follow the steps below.

1.

Loosen the thumb screw on the side grip.

►

Fig.16:

1.

 Thumb screw

2.

Attach the side grip while pressing the thumb

screw so that the grooves on the grip fit in the protru

-

sions on the tool barrel.

►

Fig.17:

1.

 Thumb screw

3.

Tighten the thumb screw to secure the grip. The

grip can be fixed at desired angle.

Grease

Coat the shank end of the drill bit beforehand with a

small amount of grease (about 0.5 - 1 g).

This chuck lubrication assures smooth action and lon-

ger service life.

Installing or removing drill bit

Clean the shank end of the drill bit and apply grease

before installing the drill bit.

►

Fig.18:

1.

 Shank end

2.

 Grease

Insert the drill bit into the tool. Turn the drill bit and push

it in until it engages.

After installing the drill bit, always make sure that the

drill bit is securely held in place by trying to pull it out.

►

Fig.19:

1.

 Drill bit

To remove the drill bit, pull the chuck cover down all the

way and pull the drill bit out.

►

Fig.20:

1.

 Drill bit

2.

 Chuck cover
