14 ENGLISH

FUNCTIONAL DESCRIPTION

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before adjusting or checking function on the tool.

Installing or removing battery cartridge

CAUTION:

Always switch off the tool before

installing or removing of the battery cartridge.

CAUTION:

Hold the tool and the battery cartridge

firmly when installing or removing battery cartridge.

Failure to hold the tool and the battery cartridge firmly may

cause them to slip off your hands and result in damage to

the tool and battery cartridge and a personal injury.

►

Fig.1:

1.

 Red indicator

2.

 Button

3.

 Battery cartridge

To remove the battery cartridge, slide it from the tool

while sliding the button on the front of the cartridge.
To install the battery cartridge, align the tongue on the

battery cartridge with the groove in the housing and slip

it into place. Insert it all the way until it locks in place

with a little click. If you can see the red indicator on the

upper side of the button, it is not locked completely.

CAUTION:

Always install the battery cartridge fully

until the red indicator cannot be seen.

 If not, it may accidentally

fall out of the tool, causing injury to you or someone around you.

CAUTION:

Do not install the battery cartridge

forcibly.

 If the cartridge does not slide in easily, it is

not being inserted correctly.

Indicating the remaining battery capacity

Only for battery cartridges with the indicator

►

Fig.2:

1.

 Indicator lamps

2.

 Check button

Press the check button on the battery cartridge to indicate the remain-

ing battery capacity. The indicator lamps light up for a few seconds.

Indicator lamps

Remaining

capacity

Lighted

Off

Blinking

75% to 100%

50% to 75%

25% to 50%

0% to 25%

Charge the

battery.

The battery

may have

malfunctioned.

NOTE:

 Depending on the conditions of use and the ambient tem-

perature, the indication may differ slightly from the actual capacity.

Tool / battery protection system

The tool is equipped with a tool/battery protection sys-

tem. This system automatically cuts off power to the

motor to extend tool and battery life. The tool will auto-

matically stop during operation if the tool or battery is

placed under one of the following conditions:

Overload protection

When the battery is operated in a manner that causes

it to draw an abnormally high current, the tool automat-

ically stops without any indication. In this situation, turn

the tool off and stop the application that caused the tool

to become overloaded. Then turn the tool on to restart.

Overheat protection

When the tool or battery is overheated, the tool stops

automatically. In this case, let the tool and battery cool

before turning the tool on again.

NOTE:

 When the tool is overheated, the lamp blinks.

Overdischarge protection

When the battery capacity is not enough, the tool stops

automatically. In this case, remove the battery from the

tool and charge the battery.

Switch action

WARNING:

Before installing the battery car

-

tridge into the tool, always check to see that the

switch trigger actuates properly and returns to

the "OFF" position when released.

►

Fig.3:

1.

 Switch trigger

To start the tool, simply pull the switch trigger. Tool

speed is increased by increasing pressure on the switch

trigger. Release the switch trigger to stop.

Speed change

The revolutions and blows per minute can be adjusted

by turning the adjusting dial. The dial is marked 1 (low

-

est speed) to 5 (full speed).

►

Fig.4:

1.

 Adjusting dial

Refer to the table below for the relationship between the

number on the adjusting dial and the revolutions and

blows per minute.

Number

Revolutions per

minute

Blows per minute

5

980

5,000

4

810

4,130

3

640

3,260

2

470

2,400

1

300

1,550

CAUTION:

Do not turn the adjusting dial when

the tool is running. Failure to do so may result in

the loss of control of the tool and cause an injury.
