12

 | English

1 609 92A 0FN | (23.1.14)

Bosch Power Tools

Hammer Safety Warnings

Wear ear protectors.

Exposure to noise can cause hear-

ing loss.

Use auxiliary handle(s), if supplied with the tool.

Loss

of control can cause personal injury.

Hold power tool by insulated gripping surfaces, when
performing an operation where the cutting accessory
may contact hidden wiring or its own cord.

Cutting ac-

cessory contacting a “live” wire may make exposed metal
parts of the power tool “live” and could give the operator an
electric shock.

Use suitable detectors to determine if utility lines are
hidden in the work area or call the local utility company
for assistance.

Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-
sion. Penetrating a water line causes property damage or
may cause an electric shock.

When working with the machine, always hold it firmly
with both hands and provide for a secure stance.

The

power tool is guided more secure with both hands.

Secure the workpiece.

A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.

Always wait until the machine has come to a complete
stop before placing it down.

The tool insert can jam and

lead to loss of control over the power tool.

Products sold in GB only

: Your product is fitted with a

BS 1363/A approved electric plug with internal fuse (ASTA
approved to BS 1362).
If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.

Products sold in AUS and NZ only

: Use a residual current de-

vice (RCD) with a rated residual current of 30 mA or less.

Product Description and Specifica-
tions

Read all safety warnings and all instruc-
tions.

Failure to follow the warnings and in-

structions may result in electric shock, fire
and/or serious injury.

While reading the operating instructions, unfold the graphics
page for the machine and leave it open.

Intended Use

The machine is intended for hammer drilling in concrete,
brick and stone as well as for chiselling.

Product Features

The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.

1

Dust protection cap

2

Locking sleeve

3

Mode selector switch

4

Vibration damper

5

On/Off switch

6

Handle (insulated gripping surface)

7

Thumbwheel for speed preselection/impact frequency
preselection

8

Service indicator

9

Stand-by indicator

10

Auxiliary handle (insulated gripping surface)

Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.

Technical Data

Noise/Vibration Information

Measured sound values determined according to EN 60745.

Typically the A-weighted noise levels of the product are:
Sound pressure level 93 dB(A); Sound power level
104 dB(A). Uncertainty K = 3 dB.

Wear hearing protection!

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to EN 60745:
Hammer drilling into concrete: a

h

= 10.5 m/s

2

, K = 4.4 m/s

2

,

Chiselling: a

h

= 7.5 m/s

2

, K = 1.5 m/s

2

.

The vibration level given in this information sheet has been
measured in accordance with a standardised test given in
EN 60745 and may be used to compare one tool with anoth-
er. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different

Rotary Hammer

GBH 5-40 DCE

Article number

3 611 B64 0..

Rated power input

W

1 150

Speed

min

-1

170 – 340

Impact rate
– Drilling  mode
– Chiselling  mode

min

-1

min

-1

1 500 – 2 900
1 500 – 3 050

Impact energy per
stroke according to
EPTA-Procedure 05/2009

J

8.8

Chisel positions

12

Tool holder

SDS-max

Lubrication

Central permanent

lubrication

Max. drilling dia.
– Concrete (with twist drill)
– Concrete

(with break-through drill bit)

– Brickwork (with core bit)

mm

mm
mm

40

55
90

Weight according to
EPTA-Procedure 01/2003

kg

6.8

Protection class

/

II

The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.

OBJ_BUCH-1742-003.book  Page 12  Thursday, January 23, 2014  9:49 AM
