Defect and error management

* For read retry count, every tick ~ 5% of total error recovery. Valid range setting is 1-20.

                     e.g. 1 ~ 5%

                            5 ~ 25%

                           20 ~ 100%

Setting these retry counts to a value below the default setting could result in degradation of the unrecovered error rate. For example, suppose the

read/write recovery page has the RC bit = 0 and if the read retry count is set to 5, this means ~ 25% of error recovery will be executed which

consumes 621.62 ms (please refer to the table above). If the limit is reached and a LBA has not yet been recovered (i.e. requires retries beyond

621.62 ms), the command will end with Check Condition status report and unrecoverable read error will be reported.

9.3

SAS system errors

Information on the reporting of operational errors or faults across the interface is given in the

SAS Interface Manual

. The SSP Response returns

information to the host about numerous kinds of errors or faults. The Receive Diagnostic Results reports the results of diagnostic operations
performed by the drive.

Status returned by the drive to the initiator is described in the

SAS Interface Manual.

 Status reporting plays a role in systems error management

and its use in that respect is described in sections where the various commands are discussed.

9.4

Deferred Auto-Reallocation

Deferred Auto-Reallocation (DAR) simplifies reallocation algorithms at the system level by allowing the drive to reallocate unreadable locations on

a subsequent write command. Sites are marked for DAR during read operations performed by the drive. When a write command is received for an

LBA marked for DAR, the auto-reallocation process is invoked and attempts to rewrite the data to the original location. If a verification of this
rewrite fails, the sector is re-mapped to a spare location.

This is in contrast to the system having to use the Reassign Command to reassign a location that was unreadable and then generate a write

command to rewrite the data. DAR is most effective when AWRE and ARRE are enabled—this is the default setting from the Seagate factory. With

AWRE and ARRE disabled DAR is unable to reallocate the failing location and will report an error sense code indicating that a write command is
being attempted to a previously failing location.

9.5

Idle Read After Write

Idle Read After Write (IRAW ) utilizes idle time to verify the integrity of recently written data. During idle periods, no active system requests, the

drive reads recently written data from the media and compares it to valid write command data resident in the drives data buffer. Any sectors that
fail the comparison result in the invocation of a rewrite and auto-reallocation process. The process attempts to rewrite the data to the original
location. If a verification of this rewrite fails, the sector is re-mapped to a spare location.

Table 4

Read and write retry count maximum recovery time

Read retry count*

Maximum recovery time per
LBA (cumulative, ms)

Write retry count*

Maximum recovery time per
LBA (cumulative, ms)

0

35.94

1

124.32

1

53.91

5

621.62

2

79.89

10

1243.23

3

97.86

15

1864.85

4

175.85

20 (default)

2486.47

5 (default)

421.79
