Operation and Storage Manual

EN

of illumination of all LEDs. Upon pressing any of the

buttons the brightness increases for 8 seconds and it is

then reduced again.

g.

If the display shows “t0” or “t1“, this means that the

self-diagnostic system has found a problem with the

temperature sensor. “t0” indicates a disconnected

cable at the sensor, while “t1” indicates short circuit

at the sensor. In this case the electric convector will

be automatically switched off and it can be switched

on again only after the problem has been fixed. The

problem has to be handled by a qualified specialist.

h.

Upon switching on the power supply the display

will show hyphens “----“ for 2 seconds instead of

temperature of time.

i.

When the digital display shows the temperature the

“Temperature” LED is lit, and when it shows the time,

the “Timer” LED is lit.

PROTECTION

 •

The appliance is equipped with a safety thermo turn-

off device, which automatically turns the heater off in

cases of extreme temperature of the panel heater /i.e.

overheating of the appliance/.

 •

The safety thermo turn-off device will automatically

restore the heater operation when the temperature

of the appliance falls below the permissible ultimate

values.

CLEANING

 •

It is compulsory first to turn off the appliance

through its power switch and to disconnect it from

the power socket. Before starting the cleaning

session you should wait until the panel heater cools

down in a disconnected state.

 •

The panel heater can be cleaned with little efforts at

the appliance rear part – just press the “P”-shaped

braces /figure 2/ at the back of the appliance so

that you can dismantle it and consequently you can

clean the rear part of the appliance.

 •

Clean the heater body with damp cloth, vacuum

cleaner or a brush.

 •

Never immerse the appliance into water – there is

danger for your life from electric shock!

 •

Never use gasoline, thinner or hard abrasive

products to clean the appliance, because they will

damage the appliance coating.

STORAGE

 •

Before putting the panel heater away let it cool

down after you have disconnected it from the

power socket

 •

Use the appliance original packing to store it, if the

panel heater will not be in use for a long period of

time. By storing the product in its original packing you

protect it from excessive dirt and dust accumulation.

 •

Never put a hot panel heater in its packing!

 •

It is necessary the product to be stored at a dry and

dark place, protected from direct sun light.

 •

It is explicitly forbidden to store the panel heater in

damp and wet premises.

MAINTENANCE OPERATIONS OF THE APPLIANCE

 •

In case of appliance malfunction, please contact the

authorized service center closest to your location. /

service centers are indicated in appliance warranty

documents/.

•

Important

: In case of a claim and/or violation of

your consumer rights, please contact the supplier of

this appliance at the indicated locations or via the

Internet page of the company: www.tesy.com

DIMENSIONS OF HEATED VOLUME AND HEATED
AREA OF A ROOM / APPLIANCE MODELS

Model

Heated volume  Heated area

CN 04 050 EIS W

 - 500W

10* - 15 m

3

4* - 6 m

2

CN 04 100 EIS W

- 1000W

20* - 30 m

3

8* - 12 m

2

CN 04 150 EIS W

 - 1500W

30* - 45 m

3

12* - 18 m

2

CN 04 200 EIS W

 - 2000W

40* - 60 m

3

16* - 24 m

2

CN 04 250 EIS W

 - 2500W

50* - 70 m

3

20* - 28 m

2

CN 04 300 EIS W

 - 3000W

60* - 80 m

3

24* - 32 m

2

* Minimum guaranteed heated volume (area) for heating at an average

capacity of heat transmission factor λ=0.5 W/(m

2

K) for a heated room.

Higher values of heated volume (area) can be achieved at an average

value of λ=0.35 W/ (m

2

K). Standard height of heated rooms – 2.5 meters.

Warning: Do not cover the appliance

in order to prevent overheating!

Environment protection instructions

Obsolete electric appliances contain valuable

materials and consequently they should not

be treated as domestic waste! We ask for your

cooperation and your active contribution to protect

the resources and the environment. Please submit

your out-of-use appliances to the organized buy-back

stations (if there are such).
