16

17

Filling for meatballs,

kebbe etc.

Push the filling with the pusher and fill with

it meatballs and kebbe.

It is recommended to use a small

attachment.

11

.

Meatballs attachment

13

Forming meatballs, kebbe

etc.

Cut the ingredients into pieces 3x3x3 cm,

then marinate them. Thoroughly stir the

mince.

Meatballs may be formed from prepared

mince and from pieces of meat. Follow

the instructions on proper device

assemble.

Grater attachment small/big

14

,

15

For the ingredients not to scattered, put a

required size container under the cutting

block.

Preparing salads, snacks,

vegetables for soups and

main dishes.

Cut the ingredients into pieces, press

them to the grater with the pusher.

Slicer attachment

16

Slicing, preparing salads

I

ngredients must be dense

(cucumbers, radishes, fresh potatoes,

carrots, cabbage, etc., sausages,

hard cheese, etc.) Cut them (if

necessary) into portions. Promote

starting ingredients pusher lightly

pressing them to the knives. Push the

ingredients with the pusher into the

blades.

Nozzle for juicing soft fruits/vegetables

19

Juicing soft fruits and

vegetables

Remove seeds from peaches, apricots,

cherries, plums. Cut the ingredients into

pieces.

You can juice the pulp several times to get

more juice. Do not juice ingredients with

seeds, the size of the hole in the sieve (for

example, raspberries, blackberries, etc.).

CLEANING AND MAINTENANCE,

Рiс. D

•   Clean  all  the  parts  of  the  meat  grinder

immediately after use.

•   Turn off the device. Unplug it.
•   Disassemble the meat grinder.
•   Thoroughly wash all removable parts of the device in a

warm water with non-abrasive detergents.

•  Non-metallic  par ts  can  be  washed  in  the

dishwasher.

Water temperature must not be

higher than 60°C.

•  Wipe the body of the device with a damp cloth.
  In  order  to  prevent  electrical  shock  do  not  im

-

merse the device into the water.

•  Thoroughly dry all the parts.

After  cleaning,  wipe  dry  the  metallic  parts  of

the meat grinder to avoid rust. For  additional

protection,  you  can  slightly grease them with

vegetable oil.

PoSSIBLE PRoBLEMS AND SoLUTIoNS

Possible problems

Possible causes

Solutions

Meat grinder doesn’t turn

on.

There is no voltage in the socket.

Unplug the device and wait until the voltage nor

-

malizes.

Meat grinder stopped

working

•  Fuse  that  protects  the  device  from

overheating tripped.

•   Maybe  the  automatic  engine  over

-

heat protection turned on

•   You  may  need  to  get  rid  of  stuck

food.

•  To  get  rid  of  the  stuck  products,  press

▼

re

. button. If this doesn’t help, unplug and

disassemble the device and clean it by your

-

self.

•  Unplug the device and contact OURSSON

service center.

There is a bad smell when

the meat grinder is working

•  Maybe the device is overheated.
•   When you turn it on for the first time

there may be a bad smell due to the

burn of the moving parts.

•  Reduce the working time with the device.
•   Bad  smell  during  first  use  isn’t  a  malfunction

and will soon disappear.

Meat is badly grinded

•

Blade is set incorrectly

•  Blades are blunt.
•  Locking ring is not set correctly.

•   Set the blade correctly.
•   Blades must be sharpened.
•    Set the locking ring correctly.

SPECIFICATIONS

*

Products must be stored in dry, ventilated warehouses at a temperature not lower than -25°С

.

PRODUCT CERTIFICATION

For information on product certification, see http://www.oursson.com or ask seller for a copy.

Only a qualified specialist from OURSSON AG service center must do the repair.

Model

 MG5000,

MG5020, MG5025

MG5530

MG5520

Power consumption, W

max 500

max 550

Rated voltage

220-240 V~; 50/60 Hz

Protection class

II

Performance  kg/h

96

96

108

Dimensions (HxWxL), mm

140х253х210

275х150х215

275х150х215

Temperature requirements

Operation

+15 tо +35°С

Storage and transportation

-25 tо +55°С

Humidity Requirements

Operation

15-75%  (without condensation)

Storage and transportation

15-75%  (without condensation)

Weight, kg

2,75

3,125

3,125
