20

3.2 S

tanDarD

 a

CCeSSorIeS

Make sure that in the product package that was bought there are the following elements:
•  high-pressure water cleaner;
•  high-pressure delivery pipe with fast coupling (only PW 140 - PW 155 - IP 1400 - IP 1550);
•  hose reel complete with high-pressure delivery pipe (only PW 150C - IP 1500S);
•  water gun;
•  lance hose;
•  rotating nozzle lance hose (only PW 150C - PW155 - IP 1500S - IP 1550);
•  foaming lance;
•  operator's instruction book;
•  accessory bag containing:

-  nozzle cleaning pin,
-  water suction hose-holding connector,
-  water suction filter;

•  bag containing (only PW 150C - IP 1500S):

-  lever for hose reel (3),
-  water cleaner/hose reel connecting pipe (5),

In case of problems, apply to the dealer or to an authorised service centre.

3.3 o

PtIonal

 a

CCeSSorIeS

The  standard  accessories  for  the  high  pressure  cleaner  can  be  integrated  with  the  following  vast  range  of
accessories:
•  Sandblasting lance: designed for smoothing down surfaces, eliminating rust, paint, deposits etc.
•  Pipe-draining probe: designed for unblocking pipes and ducts.
•  Rotating water jet brush: designed for cleaning delicate surfaces.
•  Fixed water jet brush: for cleaning delicate surfaces;
•  Rotating  nozzle  lance  hose  (as  standard  on  PW 150C  -  PW  155  -  IP 1500S  -  IP  1550):  For  removing  strong

dirtiness.

WarnInG

•  The operation of the water cleaner may be impaired if unsuitable accessories are used and they may even make

it dangerous. Only use original accessories endorsed by the Manufacturer.

  Refer to the documents provided with the optional accessories for information regarding their general use, safety

warnings, installation and maintenance.

4  I

nStallatIon

4.1 a

SSemblInG

the

 a

CCeSSorIeS

a) Insert the lance hose (17) on the water gun (16) and tighten (operation A - Fig. 3).
b) Mount the lever (3) on the hose reel (4) (only PW 150C - IP 1500S).
c) Mount the hose (5) between the hose reel and the water cleaner, by tightening the two fast coupling connectors

(operation D - Fig. 3); unroll the hose quantity (7) that is necessary by rotating the hose reel by means of the lever (3)
(only PW 150C - IP 1500S).

d) Unroll the high-pressure hose (24), connect the fast coupling connector to the water outlet connector (6), screw

and tighten (only PW 140 - PW 155 - IP 1400 - IP 1550) (operation C - Fig. 3).

e) Screw the end of the high-pressure pipe (7 or 24) (side without fast coupling for PW 140 - IP 1400) on the water

gun thread (16) and tighten with two 17-mm box wrenches (not supplied). (operation B - Fig. 3).

f) Insert the water suction filter (26) into the water suction connector and tighten it on the water inlet connector of

the water cleaner (see Fig. 1).

4.2 C

ontrolS

anD

 C

onneCtIon

to

the

 m

aInS

 W

ater

 S

uPPly

  CautIon

•  The water supply must be able to guarantee the adequate delivery of water flow to the high pressure cleaner; refer

to the table of technical specifications.

  In case of doubt, contact a

Skilled technician

.

•  Do not supply the water cleaner with water at a temperature in excess of 50°C/122°F or below 5°C/41°F.
