GA-8N775 Motherboard

- 70 -

English

(3) Configuring RAID set in RAID BIOS

Enter the RAID BIOS setup utility to configure a RAID array. Skip this step and proceed to Section 4 if
you do not want to create RAID.

Step 1:
After the POST memory test begins and before the operating system boot begins, look for a message
which says "Press F10 to enter RAID setup utility" (Figure 6). Hit the

F10

 key to enter the RAID BIOS

setup utility.

Figure 6

Step 2:
The Define a New Array screen is the first option screen when you enter the NVIDIA RAID setup utility.
(Figure 7). You can press the TAB key to highlight through options.

Step 3:
In the RAID Mode field, use the UP or DOWN ARROW key to select a RAID mode. The supported RAID
modes include Mirroring (default), Striping, Stripe Mirroring, Spanning and Raid 5. The following is an
example of RAID 0 array creation.

Step 4:
If RAID 0 is selected(select Striping in the RAID Mode field), you can manually set the striping block
size. In the Striping Block field, use the UP or DOWN ARROW key to set the Striping Block size. The

KB

is the standard unit of Striping Block size. We recommend you leaving it to the default setting--

Optimal (64K). The size range is from 4K to 128K.

Figure 7

MediaShield IDE ROM BIOS 5.50
Copyright (C) 2005 NVIDIA Corp.

Detecting array ...

Press F10 to enter RAID setup utility ...

MediaShield RAID Utility  Feb 8 2005

- Define a New Array -

RAID Mode:

Mirroring

Striping Block:

Optimal

Free Disks
Loc

Disk Model Name

1.0.M

ST3120026AS

1.1.M

ST3120026AS

Array Disks
Loc

Disk Model Name

[ ] Add

[ ] Del

[ESC] Quit        [F6] Back      [F7] Finish      [TAB] Navigate      [

] Select      [ENTER] Popup
