GA-8GEM800  Motherboard

- 12 -

English

1-3

Installation of the CPU and Heatsink

Before installing the CPU, please comply with the following conditions:
1. Please make sure that the motherboard supports the CPU.
2 . Please take note of  the pin one marks on the processor and socket.  If you install the

CPU in the wrong direction, the CPU will not insert properly.  If this occurs, please
change the insert direction of the CPU.

3 . Please add an even layer of heat sink paste between the CPU and heatsink.
4. Please make sure the heatsink is installed on the CPU prior to system use, otherwise

overheating and permanent damage of the CPU may occur.

5. Please set the CPU host frequency in accordance with the processor specifications.  It is not

recommended that the system bus frequency be set beyond hardware specifications since it
does not meet the required standards for the peripherals.  If you wish to set the frequency
beyond the proper specifications, please do so according to your hardware specifications
including the CPU, graphics card, memory, hard drive, etc.

HT functionality requirement content :

Enabling the functionality of Hyper-Threading Technology for your computer system requires all
of the following platform components:
- CPU: An Intel

®

 Pentium 4 Processor with HT Technology

- Chipset: An Intel

®

 Chipset that supports HT Technology

- BIOS: A BIOS that supports HT Technology and has it enabled
- OS: An operation system that has optimizations for HT Technology

1-3-1 Installation of the CPU

2 . R a i s e   t h e   p r o c e s s o r   s o c k e t

handle all the way up to a  fully
r a i s e d   p o s i t i o n   ( a r o u n d   9 0
degrees) till  you hear a "click."

F u l l y   r a i s e   t h e   p r o -
cessor socket handle.

1 . Raise the processor socket handle  to

65 degrees. You maybe feel a kind of
tight.

R a i s e   t h e   p r o c e s s o r
s o c k e t   h a n d l e   t o   6 5
degrees.
