Operation

Operation

General setup page

GENERAL SETUP PAGE

TV DISPLAY
ANGLE MARK
OSD LANG
CAPTIONS
SCREEN SAVER

•  TV DISPLAY
Normal/PS: When the unit connects to the

normal TV set, the wide-screen image shows
on the full screen, but some part is cut off (4:3).

Normal/LB: When the unit connects to the

normal TV set, the wide-screen image shows
and black bars appear on the top and bottom
of screen (4:3).

Wide: Use this item when the unit is

connected with the wide screen (16:9) TV set.

•  ANGLE MARK
It will show the angle mark when playing

DVD disc with multi-angle view if selecting On.

•  OSD LANG
Select on-screen display language.
•  CAPTIONS
This function doesn’t work when the disc

without caption. The default setup is On.

•  SCREEN SAVER
If the Screen saver is set On and the unit

is switched on without a disc playing for 3
minutes, a moving picture appears on the TFT.

Dolby digital setup

DOLBY DIGITAL SETUP

DUAL MONO
DYNAMIC

•  DUAL MONO
Choose the mode of the audio output:
Stereo: choose this setting, when 5.1-

channel sound playing, two channels of
signals will be output from the left and right
soundtrack; when 2-channel sound playing,
stereo signal will be output.

L. Mono: the signal will be output from the

left speaker.

R. Mono: the signal will be output from the

right speaker.

Mix-mono: the signal from one channel will

be output from left and right speakers.

•  DYNAMIC
If adjusting to FULL, the audio signal peak

value will be the minimum. While adjusting to
OFF - maximum.

Use UP/DOWN cursor buttons to move the

scroll and adjust the dynamic range.

Preference setup

PREFERENCE PAGE

TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAULT
