Operation

Operation

VIDEO, AUDIO  and SYSTEM items. Touch
them on the monitor to set the desired status.

Audio adjust

1

2

3

4

5 6 7

1. Touch to return to previous menu page.
2. Touch to decrease value.
3. Touch to adjust the parameter.
4. Touch to go to first menu page.
5. Touch to increase value.
6. Touch to go to second menu page.
7. Touch to close the menu.
In this menu you can adjust volume, bass,

treble, balance (available in the first page),
fader, equalizer and loudness (available in
the second page). Touch the corresponding
parameter, then touch increase and decrease
buttons on the screen or VOL+/- buttons on
the RC or rotate VOL regulator on the panel
to adjust the selected parameter. To adjust
Equalizer and Loudness, touch   and   icons.
After adjustment is performed, leave the unit
idle for several seconds.

Video adjust

1

2

3

4

5 6

1. Touch to return to previous menu page.
2. Touch to select a parameter.
3. Touch to decrease value.
4. Touch to increase value.
5. Touch to reselt to default value.
6. Touch to close the menu.
In this menu you can adjust Brightness

(BRI), Color (COL), Contrast (CON) and Tint.
Select the corresponding item, then touch
increase and decrease buttons on the screen
or VOL+/- buttons on the RC or rotate VOL
regulator on the panel to adjust the selected
parameter. After adjustment is performed,
leave the unit idle for several seconds.

System adjust

This menu consists of 4 subpages: Time,

Touch, TV mode and Other. In each page
touch   and   icons to adjust the setting.

TIME
•  Time: select on/off clock display.
•  Time M.: Set 12-hour or 24-hour clock

display mode.

•  Hour: Set hours.
•  Minute: Set minutes.

TOUCH
After you touch this item, a cross appears

in the left top corner of the display and a tip:
“Carefully press and briefly hold stylus on
the center of the target. Repeat as the target
moves around the screen”. Press the cross at
place 1, then it will move to another corner,
press it again. Now it will move to the third
position, press it, then the last but one and the
last position. After you pressed the cross five
times, the calibration is performed.

The calibration procedure is useful when

some malfunction occur with the touch screen,
and it needs adjustment.

TV MODE
Select the TV system.

OTHERS
•  Local Area: You can select OIRT or FM

Only, to search the stations quickly in your
