Operation

Operation

General operations

Touch screen

Due to the touch screen, you can fulfill most

functions not only by pressing buttons but also
by touching the options you need.

Reset the unit

Operating the unit for the first time or after

replacing the car battery, you must reset the
unit. Press Reset button on the inner panel with
a pointed object (such as a ballpoint pen) to
set the unit to initial state.

  When some errors occur on the display,

you can also press Reset button to resume to
normal, and it will erase the clock setting and
some memorized functions.

Turning the unit on/off

Press PWR button on the RC or POWER/

MOD button on the panel to turn on the
unit. Press and hold the button more than 2
seconds to turn off the unit.

Display dimming/off

Press and hold MUT button on the panel or

/  button on the RC to dim the TFT display.

Press and hold this button again to switch off
the TFT. Press and hold for the third time to
enable the display.

Volume control

Press VOL+/VOL- buttons on the RC or

rotate VOL regulator on the unit to increase/
decrease the sound volume level.

Setting the sound characteristics

Repeatedly press SEL button on the RC or

on the unit to select the desired parameter in
the following order: VOL (volume) => BAL L.R
(balance left-right) => FAD R.F (fader rear/front)
=> BAS (bass) => TRE (treble). After selecting
the desired parameter, you can adjust its current
level by pressing VOL+/- buttons on the RC or
rotating VOL regulator on the unit.

Mute function

Press   button on the RC or MUT button on

the unit to turn off the sound. Press the button
again or adjust volume to resume the sound
output.

Equalizer setting

While listening to music, you can select

the corresponding preset modes to adjust the
sound quality perfectly by using AF/EQ button
on the panel or on the RC. Press and hold
the button repeatedly to choose the following
modes in turn: POP => CLASS => ROCK =>
Off (no equalizer).

Loudness

Press and hold TA/LOUD button on the RC

or LOUD/TA button on the panel to activate
loudness function. This is to increase the low
frequency, which can improve sensitivity for your
ears. Keep pressing it again to quit this function.

Mode selection

•  Repeatedly press MODE button on the RC

or POWER/MOD button on the unit to select a
mode: Radio => Media => TV => AV1 => AV2.

•  In any mode touch

 item on the screen

to display the Main menu. In the menu, touch
the item of the mode you need to select the
corresponding mode.

  The Media mode is only available

when a disc, USB or SD/MMC card is inserted
into the unit. IPOD and BT modes are not
supported by this unit.

Clear

After inputting false data, press CLEAR

button to clear it.

System setup

In any mode touch

 icon to go to setup

mode. When you select setup mode, the menu
will be displayed, in which you can touch any
item to perform operations. Setup menu includes
