14

Operation

which has different PI and no RDS signal with
high field strength.

•  EON TA DX/LOCAL: EON (Enhanced

Other Networks) - This unit is equipped with
the latest technology of EON control, so that
when you are listening to Radio or CD, if there
is any travel announcement from a nearby
local station, the radio will already know the
frequency of that radio station. Then it will
receive the station, turn up the volume, or
interrupt the playback for the duration of the
announcement. At the end of the announcement
the radio will return to its previous state ready
for the next announcement.

•  REG ON/OFF: When REG is available (On),

the receiver accepts regional variants of the
tuned station display. When REG is unavailable
(Off), the receiver ignores regional variants.

•  TA VOL: You can set the default volume of

TA announcement. Support 50 levels. Default
level is 15.

Disc/USB/SD/MMC operations

USB/SD/MMC notes

USB format supports 2.0. Capacity: up to 8

Gb.

For correct and satisfactory operation,

licensed SD/MMC memory cards of famous
brands should be used with this unit. Avoid
using memory cards of unknown brands.
Capacity: up to 8 Gb.

Insert/Eject disc

•  Open the front panel and insert a disc into

the disc slot with label side up. The disc will be
automatically loaded into the unit. The first file
in the root folder will be played. Close the front
panel.

•  Open the front panel and press EJECT

button to eject the disc from the slot. If the disc
is not removed from the slot within several
seconds, it will be automatically loaded into
the slot again. When the disc is ejected and
removed, the unit will automatically switch to

another mode.

Inserting an SD/MMC card/USB device

Open the front panel and insert an SD/

MMC memory card into the card slot. Open the
USB slot cover on the front panel and insert
a USB into the USB slot. Then the playing
mode will be changed into Card or USB mode
automatically. The first card/USB device track
playback will start.

  When SD/MMC card and USB device are

both inserted, the playing mode will be changed
into the mode of the device inserted later.

Play/pause

The unit will automatically play from the first

sound track recorded on a disc/SD/MMC/USB
device. To ensure good system performance,
wait until the unit finishes reading the disc/
device information before proceeding. Press

 button on the RC or MEM/

 button on

the panel to pause playback, press it again to
resume playback.

MP3/DivX/JPEG file playback

When you insert a storage containing MP3/

DivX/JPEG file, the screen will show following
interface:

1

2

3

4

5

6

7

8

1. Storage folder list
2. Scroll bar
3. Current playback info
4. Current folder content (current file is
