10

Operation

Remote controller

1

2

3
4
5
6
7
8

9

10

16

17

18
19
20
21
22
23
24
25
26
27
28
29

11
12
13
14

15

1. POWER button
2. MODE button
3. UP cursor button
4. BND/RDM button
5. ENTER button
6. LEFT cursor button
7. DOWN cursor button
8. STEREO/MONO button
9. PTY/PROG button
10. P.SCN/RPT button
11. SEEK-

 button

12. AF/TA button
13. OSD button
14.  /PBC button

15. Number buttons
16.

 button

17. MUTE button
18. MENU button
19. SUB-T button
20. RIGHT cursor button
21. SETUP button
22. ANGLE button
23. INT button
24. VOL+ button
25. A-B/ZOOM button
26. SEL button
27. SEEK+

 button

28. VOL- button
29. AUDIO/GOTO button

Changing the battery

1. Press the catch and at the same time pull

out the battery tray.

2. Insert the 1 x lithium battery, type CR

2025 3 V with (+) mark facing up. Insert the
battery tray into the remote control.

  •  Store the battery where children

cannot reach. If a child accidentally swallows
the battery, consult a doctor immediately.

•  Do not recharge, short, disassemble or

heat the battery or dispose it in a fire.

•  Do not expose or bring into contact the

battery with other metallic materials. Doing this
may cause the battery to give off heat, crack or
start a fire.

•  When throwing away or saving the battery,

wrap it in tape and insulate; otherwise, the
battery may give off heat, crack or start a fire.

•  Please direct the Remote controller to the

IR sensor of the front panel.
