suitable protective gloves, work clothing, safety

goggles and breathing protection with a filter

element suitable for the respective application!

- There is a risk of the injection of coating material

or cleaning fluid (e.g. when changing nozzles or

during cleaning)! Serious consequence can result

if the protective equipment is inadequate (e.g.

necroses, loss of limbs). There is also a risk in the

case of inhalation, contact or absorption of coating

materials or cleaning fluids. For this reason,

always provides adequate technical or natural

ventilation!

- Do not use the equipment in potentially explosive

atmospheres. Do not process materials that can

create potentially explosive atmospheres. Ensure

that only suitable compressed air is used!

Information in these operating instructions is cate-

gorised as shown below:

Danger!

Risk of personal injury or environ-

mental damage.

Caution.

Risk of material damage

4.9

Symbols on the air tool

Read the operating instructions before

starting to use the machine.

Wear safety goggles.

Wear ear protectors.

See Page 2.

1 Flowing cups/suction cups

2 Nozzle  head

3 Regulating screw for round or wide-spray jets *

4 Air volume regulation *

5 Regulating screw for paint volume

6 Trigger  lever

7 Plug-in nipple 1/4" *

* depending on features

6.1 Before using the tool for the first time

Insert plug-in nipple (7).

6.2 Setting paint jet:
Round jet / wide-spray jet

(depending on

features)

:

Use the regulating screw (3) to set the spraying gun

to a round or wide jet. See Fig. A, Page 2.
Round jet for small surfaces, corners and edges.
Wide jet for large surfaces. The nozzle head (2) can

be turned steplessly into vertical or horizontal posi-

tion.

Paint volume (application speed):

Set the paint volume at the regulating screw (5).
Open the regulating screw  (5) by approx. 2 to 2

1

/

2

rotations and carry out a spray test.
Additional opening of the regulating screw (5)

increases the paint flow and thus the application

speed.
Closing the regulating screw  (5) reduces the paint

flow and thus the application speed.
Because the material types vary, the paint volume

adjustment should always be carried out during

operation of the paint spraying gun.

HVLP (High Volume, Low Pressure):

(depending on features)

Min. supply pressure 0.7 bar at nozzle set, transfer

rate approx. 70%. Low overspray, maximum

transfer efficiency combined with low air consump-

tion; paint savings are up to 30%.

HVLP (High Volume, Low Pressure):

(depending on features)

Min. supply pressure 0.7 bar at nozzle set, transfer

rate approx. 73%. Low overspray, maximum

transfer efficiency combined with very low air

consumption.

6.3 Using the air tool

To benefit from the air tool's full performance,

always use compressed air hoses with an inner

diameter of at least 10 mm. Tool performance can

be significantly impaired if the inner diameter is too

small.

Caution.

The compressed air line must not

contain any water condensation.

Caution.

The compressed air used must be

cleaned and be free of condensate and oil.

1. Ensure that the air volume regulation (4) (de-

pending on features) is fully open prior to oper-

ation. It can be used for fine adjustment of the

air volume during operation.

2. Adjust the supply pressure (this is measured at

the air outlet while the air tool is switched on).

For details of the maximum permissible supply

pressure, see the section on "Technical Specifi-

cations".

If the supply pressure is too high, this can result

in excessively fine distribution of the material

accompanied by rapid fluid evaporation. The

surfaces become rough with poor adherence.

If the supply pressure is too low, the material is

insufficiently atomised. The surface will be

wavy with paint drips.

3. Connect the air tool with quick-action coupling

to the compressed air supply.

4. Observe the manufacturer's instructions on

paint conditioning. Fill paint into the cup (1).

Seal with cover.

5. Actuate the trigger lever (6) to put the paint

spraying gun into operation.

6. Set the paint jet (see Section 6.2).
