Category

LFL

(kg/m

3

)

h

0

 (m)

Floor area (m

2

)

4

7

10

15

20

30

50

R290

0.038

0.6

0.05

0.07

0.08

0.1

0.11

0.14

0.18

1

0.08

0.11

0.13

0.16

0.19

0.2

0.3

1.8

0.15

0.2

0.24

0.29

0.34

0.41

0.53

2.2

0.18

0.24

0.29

0.36

0.41

0.51

0.65

R32

0.306

0.6

0.68

0.9

1.08

0.32

1.53

1.87

2.41

1

1.14

1.51

1.8

2.2

2.54

3.12

4.02

1.8

2.05

2.71

3.24

3.97

4.58

5.61

7.254

2.2

2.5

3.31

3.96

4.85

5.6

6.86

8.85

Table GG.1 - Maximum charge (kg)

INSTALLATION MANUAL

Important considerations

•  The air conditioner you buy must be installed by professional personnel and the

Installation manual is used only for the professional installation personnel! The
installation specifications should be subject to our after-sale service regulations.

•  When filling the combustible refrigerant, any of your rude operations may cause serious

injury or injuries to human body or bodies and object or objects.

•  A leak test must be done after the installation is completed.
•  It is a must to do the safety inspection before maintaining or repairing an air conditioner

using combustible refrigerant in order to ensure that the fire risk is reduced to minimum.

•  It is necessary to operate the machine under a controlled procedure in order to ensure

that any risk arising from the combustible gas or vapor during the operation is reduced
to minimum.

•  Requirements for the total weight of filled refrigerant and the area of a room to be

equipped with an air conditioner (are shown as in the following Tables GG.1 and GG.2)

The maximum charge and the required minimum floor area

m

1

 = (4 m

3

) x LFL , m

2

 = (26 m

3

) x LFL,  m

3

 = (130 m

3

 ) x LFL

Where LFL is the lower flammable limit in kg/m

3

, R290 LFL is 0.038 kg/ m

3

, R32 LFL is 0.038 kg/m

3

.

For the appliances with a charge amount

m

1

 < M = m

2

:

The maximum charge in a room shall be in accordance with the following:

m

max

 = 2.5 x (LFL)

(5/4)

 x h

0

 x (A)

1/2

The required minimum floor area A

min

 to install an appliance with refrigerant charge M (kg) shall be in accordance

with following:

A

min

 = (M/ (2.5 x (LFL)

(5/4)

 x h

0

))

2

Where:
m

max

 is the allowable maximum charge in a room, in kg;

M is the refrigerant charge amount in appliance, in kg;
A

min

 is the required minimum room area, in m

2

;

A is the room area, in m

2

;

LFL is the lower flammable limit, in kg/m

3

;

h

0

 is the installation height of the appliance,in meters for calculating m

max

 or A

min

, 1.8 m for wall mounted.
