consume ice cream, water ice or ice cubes immediately and
do not consume them too cold.
Please observe the specific information in the other
sections:
DANGER
identifies a situation involving direct
danger which, if not obviated, may
result in death or severe bodily injury.
WARNING
identifies a dangerous situation
which, if not obviated, may result in
death or severe bodily injury.
CAUTION
identifies a dangerous situation
which, if not obviated, may result in
minor or medium bodily injury.
NOTICE
identifies a dangerous situation
which, if not obviated, may result in
damage to property.
Note
identifies useful information and tips.
3 Controls and displays
3.1 Operating and control elements
Fig. 3
(1) On/Off button, refriger-
ator compartment
(12) Refrigerator compartment
temperature display
(2) Alarm symbol
(13) Down setting button, refrig-
erator compartment
(3) SuperCool button
(14) Fan symbol
(4) SuperFrost button
(15) Up setting button, refriger-
ator compartment
(5) SuperFrost symbol
(16) Child-proofing symbol
(6) On/Off button, freezer
compartment
(17) Power failure symbol
(7) Fan button
(18) Menu symbol
(8) Alarm button
(19) HomeDialog symbol
(9) Down setting button,
freezer compartment
(20) SuperCool symbol
(10) Freezer compartment
temperature display
(21) Water tank symbol*
(11) Up setting button,
freezer compartment
(22) IceMaker symbol*
3.2 Temperature display
The following are displayed in normal operation:
-
the warmest freezing temperature
-
the average cooling temperature
The freezer compartment temperature display flashes:
-
the temperature setting is being changed
-
after switch-on the temperature is not yet cold enough
-
the temperature has risen several degrees
Dashes flash in the display:
-
the freezer temperature is above 0 °C.
The following displays indicate malfunction. Possible causes and
corrective action (see Malfunction).
-
F0
to
F9
-
FE
*
-
The power failure symbol
shines.
4 Putting into operation
4.1 Changing over the door hinges
You can change over the door hinges if necessary.
Ensure that the following tools are to hand:
q
Torx 25
q
Torx 15
q
Screwdriver
q
Cordless screwdriver, if necessary
q
Second person for fitting work, if needed
4.1.1 Undo the cable connection on the housing.
Fig. 4
u
Open the upper door.
u
To remove the cover on the handle side
Fig. 4 (1): disengage
on the right using a flat-blade screwdriver and slide it
outwards.
u
To remove the cover on the hinge side
Fig. 4 (2): disengage
on the left using a flat-blade screwdriver and slide it outwards.
u
Remove the front panel
Fig. 4 (3) using a flat-blade screw-
driver.
u
Remove contact and disconnect plug connector
Fig. 4 (5).
u
Detach grey cable
Fig. 4 (6) from the guide.
4.1.2 Detaching the upper door
Note
u
Remove any food from the door racks before removing the
door, so that no food falls out.
Controls and displays
4
