The  forced-air  cooling  uses  slightly  more  energy.  To  save

energy, the fan switches off automatically when the door is open.
Switching on the fan

u

Briefly press the fan button

 Fig. 3 (7).

w

The fan symbol

 Fig. 3 (14) shines.

w

The  fan  is  active.  It  switches  on  automatically  when  the

compressor runs.

To switch off the fan

u

Briefly press the fan button

 Fig. 3 (7).

w

The fan symbol

 Fig. 3 (14) goes out.

w

The fan is switched off.

5.5.5 Relocating the shelves

The shelves have stops preventing them from being unintention-

ally pulled out.

u

Lift the shelf and draw it out forwards.

u

Insert shelf with the raised edge pointing upwards at the back.

w

The food does not freeze onto the rear wall.

5.5.6 Using the sectioned shelf

Fig. 13

u

The glass shelf with stop face (2) has to be at the back.

5.5.7 Moving the storage rack

u

Remove storage rack according to illus-

tration.

The boxes can be removed and placed on the table as a single

unit.
Only one box or both boxes can be used. If particularly tall bottles

are to be stored, attach only the wide box above the bottle rack.
Three small boxes are available through the customer service as

optional equipment instead of one wide and one small box.

u

Re-positioning the boxes: Lift them for

removal  and  re-position  them  as

required.

u

To  detach  lid:  Open  90°  and  raise  to

disengage.

5.5.8 Removing the bottle holder

u

Always take hold of the bottle holder on

the plastic part.

5.6 Freezer compartment

You can store frozen food, make ice cubes and freeze fresh food

in the freezer compartment.

5.6.1 Freezing food

The maximum weight of fresh food which can be frozen within 24

h  is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".
The maximum load of frozen food for the drawers is 25 kg each

and for the shelves 35 kg each.

CAUTION

Risk of injury due to broken glass!

Bottles and cans containing drinks may burst when being frozen.

This applies particularly to sparkling drinks.

u

Do not freeze bottles and cans containing drinks!

In order that the food is rapidly frozen through to the core, do not

exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg

- Meat up to 2.5 kg

u

Pack  the  food  in  portions  in  freezer  bags,  reusable  plastic,

metal or aluminium containers.

5.6.2 Thawing food

- in the refrigerator compartment

- at room temperature

- in a microwave oven

- in a conventional or fan oven

u

Food  once  thawed  should  be  re-frozen  only  in  exceptional

cases.

The  temperature  can  be  set  between  -16  °C  and  -26  °C ,  the

recommended temperature is -18 °C.

u

To  set  the  temperature  higher:  press  Up  button,  freezer

compartment

 Fig. 3 (11).

u

To  set  the  temperature  lower:  press  Down  button,  freezer

compartment

 Fig. 3 (9).

w

When the button is pressed the first time, the previous value

is indicated in the temperature display of the freezer compart-

ment.

u

To  change  the  temperature  in  1  °C  steps:  briefly  press  the

button.

-or-

u

To  change  the  temperature  continuously:  hold  down  the

button.

w

The value is displayed flashing during the setting operation.

w

The  actual  temperature  is  displayed  about  5  s  after  the  last

press of a button. The temperature slowly adjusts to the new

value.

5.6.4 SuperFrost

With  this  function  you  can  freeze  fresh  food  quickly  through  to

the  core.  The  appliance  operates  with  maximum  refrigeration.

The noise of the refrigeration unit may be temporarily louder as

a result.
The maximum amount of fresh food which can be frozen in 24 h

is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

Control

10
