u

Pull the water tank forwards.

u

Open the front flap and fill the

tank with water.

u

Place  the  filled  water  tank  in

the  holder  and  slide  it  all  the

way back.

Note

u

The water reservoir has to be slid all the way into the bracket

provided for the purpose in the refrigerator compartment!

Switching on the IceMaker*

Fig. 15

u

Pull out the drawer.

u

Press  the  On/Off  button

  Fig.  15  (1)  so  that  the  LED

Fig. 15 (2) shines.

u

Push in the drawer.

w

The IceMaker symbol

 Fig. 3 (22) shines.

Note

u

The  IceMaker  produces  ice  cubes  only  if  the  drawer  is  fully

closed.

Producing ice cubes*
The  production  capacity  depends  on  the  freezer  temperature.

The lower the temperature, the more ice cubes can be produced

in a specific period.
The ice cubes drop from the IceMaker into the drawer. When a

certain  filling  level  has  been  reached,  no  further  ice  cubes  are

produced. The IceMaker does not fill the drawer right up to the

brim.
If  large  quantities  of  ice  cubes  are  needed,  the  complete

IceMaker  drawer  can  be  exchanged  for  the  adjacent  drawer.

When  the  drawer  is  closed,  the  IceMaker  automatically  re-

commences production.
Once the IceMaker has been switched on for the first time, it may

take up to 24 hours until the first ice cubes are produced.

Note

When the appliance is used for the first time or if has not been

used for a long time, the IceMaker has to be rinsed to remove any

particles present.

u

Therefore do not use or consume the ice cubes made in the

first 24 hours.

Setting the water intake time*
The opening time of the IceMaker valve can be set to affect the

size of the ice cubes produced.

The water intake time is adjustable in steps from

E1

 (short intake

time) to

E8

 (long intake time).

u

To  activate  the  setting  mode:  press  the  SuperFrost  button

Fig. 3 (4) for about 5 s.

w

The display indicates

c

.

w

Themenu symbol

 Fig. 3 (18) shines.

u

Using the Up setting button, freezer compartment

 Fig. 3 (11)

and  Down  setting  button,  freezer  compartment

  Fig.  3  (9)

select

E

.

u

To confirm: briefly press the SuperFrost button

 Fig. 3 (4).

u

To  increase  the  water  intake  time:

press  the  Up  setting  button,  freezer

compartment

 Fig. 3 (11).

u

To reduce the water intake time: press

the  Down  setting  button,  freezer

compartment

 Fig. 3 (9).

u

To  confirm:  press  the  SuperFrost

button

 Fig. 3 (4).

u

To  deactivate  the  setting  mode:  press  the  On/Off  button,

freezer compartment

 Fig. 3 (6).

-or-

u

Wait for 2 minutes.

w

The temperature is indicated again in the temperature display.

Switching off the IceMaker*
If  no  ice  cubes  are  needed,  the  IceMaker  can  be  switched  off

independently of the freezer compartment.
When the IceMaker is switched off, the IceMaker drawer can also

be used for freezing and storing food.

u

Press the On/Off button for about 1 second until the LED goes

out.

w

The IceMaker symbol

 Fig. 3 (22) goes out.

u

Clean the IceMaker.

w

This ensures that no water or ice remains in the IceMaker.

6 Maintenance

6.1 Defrosting with NoFrost

The NoFrost system automatically defrosts the appliance.
Refrigerator compartment:
The defrost water evaporates due to the compressor heat. Drops

of water on the rear wall are perfectly normal.

u

Regularly  clean  the  drain  opening  to  allow  the  water  to  flow

away  (see 6.2) .

Freezer compartment:
The  moisture  condenses  on  the  evaporator,  is  periodically

defrosted and evaporates.

u

The appliance does not have to be manually defrosted.

6.2 Cleaning the appliance

Before cleaning:

CAUTION

Risk of injury and damage as a result of hot steam!

Hot steam may damage the surfaces and cause burns.

u

Do not use any steam cleaners!

Maintenance
