The  ventilation  space  under  the  ceiling  has  to  be  at  least

300 cm

2

.

-

The larger the ventilation space, the more energy-saving the

appliance is in operation.

If  the  appliance  is  installed  with  the  hinges  next  to  a  wall

Fig. 17 (4), the distance between appliance and wall has to be

at least 40 mm.

4.5 Disposing of packaging

WARNING

Danger of suffocation due to packing material and plastic film!

u

Do not allow children to play with packing material.

The packaging is made of recyclable materials:

-

corrugated board/cardboard

-

expanded polystyrene parts

-

polythene bags and sheets

-

polypropylene straps

-

nailed wooden frame with polyethylene panel*

u

Take the packaging material to an official collecting point.

4.6 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The  type  of  current  (alternating  current)  and  voltage  at  the

installation site have to conform with the data on the type plate

(see Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.
It must be easily accessible so that the appliance can

be quickly disconnected from the supply in an emer-

gency.

u

Check the electrical connection.

u

Plug in the power plug.

4.7 Switching on the appliance

Note

u

To  switch  on  the  entire  appliance  it  is  necessary  only  to

switch on the freezer compartment.

Put  the  appliance  into  operation  about  2  hours  before  first

loading food to be frozen.
Do  not  load  food  to  be  frozen  before  the  temperature  display

reads -18 °C.

4.7.1 Switching on the freezer compartment

u

Press On/Off button, freezer compartment

 Fig. 3 (17).

w

The  temperature  display  of  the  refrigerator  compartment

indicates the current temperature inside.

w

The temperature display of the freezer compartment and the

alarm symbol flash until the temperature is sufficiently low. If

the  temperature  is  above  0  °C,  dashes  flash.  If  it  is  below,

the current temperature flashes.

5 Control

5.1 Brightness of the temperature

display

You can adjust the brightness of the temperature display to the

light conditions of the room in which the appliance is installed.

5.1.1 Adjusting the brightness

The  brightness  is  adjustable  between

h0

  (no  illumination)  and

h5

 (maximum luminosity).

u

To  activate  the  setting  mode:  press  the  SuperFrost  button

Fig. 3 (18) for about 5 s.

w

The display indicates

c

.

w

The menu symbol

 Fig. 3 (10) shines.

u

Using the Up setting button, freezer compartment

 Fig. 3 (15)

or  Down  setting  button,  freezer  compartment

  Fig.  3  (16),

select

h

.

u

To confirm: briefly press the SuperFrost button

 Fig. 3 (18).

u

To  make  the  display  brighter:  press  Up  button,

freezer compartment

 Fig. 3 (15).

u

To  make  the  display  darker:  press  Down  button,

freezer compartment

 Fig. 3 (16).

u

To confirm: press SuperFrost button

 Fig. 3 (18).

w

The brightness is adjusted to the new value.

u

To deactivate the set-up mode: press On/Off button, freezer

compartment

 Fig. 3 (17).

-or-

u

Wait for 5 minutes.

w

The  temperature  is  indicated  again  in  the  temperature

display.

5.2 Child proofing

The  child-proofing  function  enables  you  to  make  sure  that  the

appliance is not inadvertently switched off by playing children.

5.2.1 Setting the child lock function

u

To  activate  the  setting  mode:  press  SuperFrost  button

Fig. 3 (18) for about 5 s.

w

The display indicates

c

.

w

The menu symbol

 Fig. 3 (10) shines.

u

Briefly press the SuperFrost button

 Fig. 3 (18).to confirm.

When

c1

 is indicated in the display:

u

Tto  activate  the  child  lock,  briefly  press  the

SuperFrost button

 Fig. 3 (18).

w

The  child  lock  symbol

  Fig.  3  (9)  shines.

c

  flashes  in  the

display.

When

c0

 is indicated in the display:

u

to  deactivate  the  child  lock,  briefly  press  the  SuperFrost

button

 Fig. 3 (18).

w

The  child  lock  symbol

  Fig.  3  (9)  goes  out.

c

  flashes  in  the

display.

u

To deactivate the set-up mode: press On/Off button, freezer

compartment

 Fig. 3 (17).

-or-

u

Wait for 5 minutes.

w

The  temperature  is  indicated  again  in  the  temperature

display.

5.3 Door alarm

For  refrigerator/BioFresh  compartment  and  freezer  compart-

ment
If the door is open longer then 60 s, the audible alarm sounds.
The  audible  alarm  is  automatically  silenced  when  the  door  is

closed.

Control

9
