5.3.1 Muting the door alarm

The  audible  alarm  can  be  muted  when  the  door  is  open.  The

sound  switch-off  function  is  active  as  long  as  the  door  is  left

open.

u

Press alarm button

 Fig. 3 (19).

w

The door alarm is silenced.

5.4 Temperature alarm

The audible alarm sounds if the freezer temperature is not cold

enough.
The temperature display and the alarm symbol

 Fig. 3 (14) flash

at the same time.
The cause of the temperature being too high may be:

-

warm fresh food was placed inside

-

too much warm ambient air flowed in when rearranging and

removing food

-

power failure for some time

-

the appliance is faulty

The  audible  alarm  is  automatically  silenced,  the  alarm  symbol

Fig. 3 (14) goes out and the temperature display stops flashing

when the temperature is sufficiently cold again.
If the alarm status persists: (see Malfunction).

Note

Food may be spoilt if the temperature is not cold enough.

u

Check the quality of the food. Do not consume spoiled food.

5.4.1 Muting the temperature alarm

The  audible  alarm  can  be  muted.  When  the  temperature  is

sufficiently cold again, the alarm function is active again.

u

Press alarm button

 Fig. 3 (19).

w

The audible alarm is silenced.

5.5 Refrigerator compartment

The  natural  circulation  of  air  in  the  refrigerator  compartment

results  in  zones  differing  in  temperature.  It  is  coldest  directly

above  the  plate  separating  off  the  BioFresh  zone  and  at  the

rear wall. It is warmest at the top front of the compartment and

in the door.

5.5.1 Food refrigeration

Note

The  energy  consumption  increases  and  the  cooling  perform-

ance decreases if the ventilation is inadequate.

u

Always keep the air slits of the fan free.

u

Place butter and preserves in the upper area and in the door

(see Appliance at a glance).

u

Use  recyclable  plastic,  metal,  aluminium  and  glass

containers and cling film for wrapping.

u

Use the front area of the refrigerator compartment floor only

for  briefly  putting  down  cooled  products,  e.g.  when  rear-

ranging  and  sorting.  However  do  not  leave  cooled  products

there  otherwise  they  may  be  pushed  back  or  tipped  over

when the door is closed.

u

Do  not  store  food  too  close  together  to  enable  good  air

circulation.

u

To  safeguard  bottles  from  tipping  over:  move  the  bottle

holder.

At  the  base  of  the  refrigerator  compartment,  the  integrated

bottle shelf or alternatively the glass shelf can be used:

u

To  use  the  bottle  shelf:

store  the  glass  shelf

compactly  under  the

bottle shelf.

u

Place the bottles with the

base pointing backwards

facing the rear wall.

If  the  bottles  project

beyond the bottle shelf:

u

set  the  lower  door  rack

one position higher.

5.5.2 Setting the temperature

The  temperature  can  be  set  from  9  °C  to  3  °C,  the  recom-

mended temperature is 5 °C.

u

For  a  higher  temperature  setting:  press  Up  button,  refriger-

ator compartment

 Fig. 3 (4).

u

For  a  lower  temperature  setting:  press  Down  button,  refrig-

erator compartment

 Fig. 3 (5).

w

The  first  time  the  button  is  pressed,  the  value  set  so  far  is

indicated  in  the  refrigerator  compartment  temperature

display.

u

To  change  the  temperature  in  1  °C  steps:  briefly  press  the

button.

u

To  change  the  temperature  continuously:  hold  down  the

button.

w

The value is displayed flashing during the setting operation.

w

The  actual  temperature  is  displayed  about  5  s  after  the  last

press of a button. The temperature slowly adjusts to the new

value.

5.5.3 SuperCool

With SuperCool you switch to the highest cooling performance

to reach lower cooling temperatures. Use SuperCool, to rapidly

cool large amounts of food.
When  SuperCool  is  activated,  the  fan  runs.  The  appliance

operates with maximum refrigeration. The noise of the refriger-

ation unit may be temporarily louder as a result.
The SuperCool function uses slightly more energy.
Cooling with SuperCool

u

Briefly press SuperCool button

 Fig. 3 (2).

w

The SuperCool symbol

 Fig. 3 (7) lights up in the display.

w

The  cooling  temperature  drops  to  the  coldest  value.  Super-

Cool is activated.

w

SuperCool  is  automatically  deactivated  after  6  to12  hours

The  appliance  continues  to  operate  in  the  energy-saving,

normal mode.

To prematurely deactivate SuperCool

u

Briefly press SuperCool button

 Fig. 3 (2).

w

The SuperCool symbol

 Fig. 3 (7) goes out in the display.

w

SuperCool is deactivated.

5.5.4 Holiday mode

The  holiday  mode  saves  energy  and  prevents  odour  from

occurring  when  the  door  of  the  refrigerator  compartment  stays

closed for a lengthy period.
The  freezer  compartment  remains  in  operation  in  the  holiday

mode.
Activating the holiday mode

u

Remove all the food from

the

refrigerator

and

BioFresh  compartment,

otherwise

they

will

perish..

u

Press  the  holiday  button

Fig. 3 (1) for 3 sec.

w

The holiday mode is activated. The display indicates

Ho

.

Control
