Do not place any burning candles, lamps or other items with

naked flames on or in the appliance.

-

Only store high-percentage alcohol in tightly sealed, upright

containers.  Alcohol  possibly  escaping  may  ignite  due  to

electrical components.

Danger of tipping and falling:

-

Do not misuse the plinth, drawers, doors etc. as a step or for

support. This applies particularly to children.

Danger of food poisoning:

-

Do not consume food which has been stored too long.

Danger of frostbite, numbness and pain:

-

Avoid lasting skin contact with cold surfaces or refrigerated/

frozen  food  or  take  protective  steps,  e.g.  wear  gloves.  Do

not consume ice cream, water ice or ice cubes immediately

and do not consume them too cold.

Please  observe  the  specific  information  in  the  other

sections:

DANGER

identifies a situation involving direct

danger which, if not obviated, may

result in death or severe bodily

injury.

WARNING

identifies a dangerous situation

which, if not obviated, may result in

death or severe bodily injury.

CAUTION

identifies a dangerous situation

which, if not obviated, may result in

minor or medium bodily injury.

NOTICE

identifies a dangerous situation

which, if not obviated, may result in

damage to property.

Note

identifies useful information and tips.

3 Controls and displays

3.1 Operating and control elements

Fig. 3

(1) Holiday button

(11) HomeDialog symbol

(2) SuperCool button

(12) Freezer compartment

temperature display

(3) On/Off button, refriger-

ator compartment

(13) SuperFrost symbol

(4) Up setting button, refrig-

erator compartment

(14) Alarm symbol

(5) Down setting button,

refrigerator compart-

ment

(15) Up setting button, freezer

compartment

(6) Power failure symbol

(16) Down setting button,

freezer compartment

(7) SuperCool symbol

(17) On/Off button, freezer

compartment

(8) Refrigerator compart-

ment temperature

display

(18) SuperFrost button

(9) Child lock symbol

(19) Alarm button

(10) Menu symbol

3.2 Temperature display

The following are displayed in normal operation:

-

the warmest freezing temperature

-

the average cooling temperature

The freezer compartment temperature display flashes:

-

the temperature setting is being changed

-

after switch-on the temperature is not yet cold enough

-

the temperature has risen several degrees

Dashes flash in the display:

-

the freezer temperature is above 0 °C.

The  following  displays  indicate  malfunction.  Possible  causes

and corrective action (see Malfunction).

-

F0

 to

F9

-

The power failure symbol

shines.

4 Putting into operation

4.1 Transporting the appliance

CAUTION

Risk  of  injury  and  danger  of  damage  as  a  result  of  incorrect

transport!

u

Transport the appliance in a packed condition.

u

Transport the appliance upright.

u

Do not transport the appliance without assistance.

4.2 Installing the appliance

In the event that the appliance is damaged, contact the supplier

immediately before connecting to the mains.
The floor at the site must be flat and level.
Do not install the appliance in a location where it is exposed to

direct radiation of the sun, next to a cooker, heater and similar.
Always  install  the  appliance  with  the  back  directly  against  the

wall.
Do not install the appliance without assistance.
Standard  EN  378  specifies  that  the  room  in  which  you  install

your  appliance  must  have  a  volume  of  1  m

2

  per  8  g  of  R  600a

refrigerant used in the appliance. If the room in which the appli-

ance  is  installed  is  too  small,  a  flammable  gas-air  mixture  may

form  in  the  event  of  a  leakage  in  the  refrigeration  circuit.  The

quantity of refrigerant used in your appliance is indicated on the

type plate on the inside of the appliance.
The appliance may be moved only when it is empty.

CAUTION

Risk of injury and damage!

The glass door may strike against the wall and be damaged as

a result. The fractured glass may lead to injury!

u

Protect  the  glass  door  from  striking  against  the  wall.  Fit  a

door stop, e.g. one made of felt, to the wall.

u

A limiter restricting door opening to 90° can be ordered from

the aftersales service.

Controls and displays

4
