The  moisture  condenses  on  the  evaporator,  is  periodically

defrosted and evaporates.

u

The appliance does not have to be manually defrosted.

6.2 Cleaning the appliance

Before cleaning:

CAUTION

Risk of injury and damage as a result of hot steam!

Hot steam may damage the surfaces and cause burns.

u

Do not use any steam cleaners!

NOTICE

Incorrect cleaning damages the appliance!

u

Do not use cleaning agents in concentrated form.

u

Do not use any scouring or abrasive sponges or steel wool.

u

Do  not  use  any  cleaning  agents  containing  sand,  chloride,

chemicals or acid.

u

Do not use chemical solvents.

u

Do not damage or remove the type plate on the inside of the

appliance. It is important for the customer service.

u

Do  not  pull  off,  bend  or  damage  cables  or  other  compo-

nents.

u

Do  not  allow  any  cleaning  water  to  enter  the  drain  channel,

ventilation grille or electrical parts.

u

Empty the appliance.

u

Pull out the plug.

- Use  soft  cleaning  cloths  and  a  multi-purpose

cleaning agent with neutral pH value.

- Only  use  food  compatible  cleaning  and  care

agents on the inside of the appliance.

Outside surfaces and interior:

u

Clean  the  plastic  surfaces,  outside  and  inside,  by  hand

using lukewarm water and a little washing-up liquid.

NOTICE

The  stainless  steel  doors  are  provided  with  a  high-quality

surface  coating  and  must  not  be  treated  using  the  accompa-

nying care product.

Otherwise the surface coating will be affected.

u

Wipe  the  coated  door  surfaces  using  a  soft,  clean  cloth

only.  In  case  of  stubborn  dirt,  use  a  little  water  or  a  neutral

cleaning agent. A microfibre cloth can be optionally used.

u

If the stainless steel side walls are dirty, clean them using

a  commercially  available  stainless  steel  cleaning  agent.

Then  evenly  apply  the  accompanying  stainless  steel  care

product, making strokes in the direction of the grain.

u

Wipe  side  walls  with  a  paint  finish  using  a  soft,  clean

cloth  only.  In  case  of  stubborn  dirt,  use  a  little  water  or  a

neutral  cleaning  agent.  A  microfibre  cloth  can  be  optionally

used.

Do  not  apply  stainless  steel  cleaning  agent  to  glass  or  plastic

surfaces to prevent them from being scratched. Darker areas at

the  beginning  and  quite  an  intensive  colour  of  the  stainless

steel surface are normal.

u

To  clean  the  drain  opening:  remove

any  deposits  with  a  fine  instrument,

e.g. a cotton bud.

Items of equipment:

u

Clean items of equipment by hand with lukewarm water and

a little washing-up liquid.

u

For  cleaning,  remove  the  support  rails  for  the  half-sized

glass shelves.

u

To  dismantle  the  shelves:  remove

the trims and side parts.

u

To  dismantle  the  storage  rack:

remove  the  protective  film  from  the

decorative trims.

u

Lift  out  the  boxes  and  lift  the  covers

for removal.

After cleaning:

u

Wipe dry the appliance and items of equipment.

u

Connect the appliance and switch it on again.

u

Switch on SuperFrost (see 5.7.4) .

When the temperature is sufficiently cold:

u

Put the food back inside.

6.3 Changing the interior light with bulb

Bulb data

T25 tube, Philips

max. 25 W

Fitting: E14

Type of current and voltage must conform with the details on

the type plate

Fig. 18

u

Switch off the appliance.

u

Pull out the power plug or switch off the fuse.

u

To  remove  the  cover

  Fig.  18  (1):  put  your  finger  behind  the

cover and disengage it.

u

Pull out the glass shelf

 Fig. 18 (2).

u

Change the bulb

 Fig. 18 (3).

u

Slide the glass shelf back in.

u

Attach  the  cover  again,  engage  it  at  the  right  and  left  and

pay attention that the middle hook

 Fig. 18 (4) grips over the

glass shelf.

6.4 Customer service

First  check  whether  you  can  correct  the  fault  yourself  by  refer-

ence to the list (see Malfunction). If this is not the case, please

contact  the  customer  service  whose  address  is  given  in  the

enclosed customer service list.

WARNING

Risk of injury if repair work is not carried out professionally!

u

Have  any  repairs  and  action  -  not  expressly  specified  -  on

the  appliance  and  mains  cable  carried  out  by  service

personnel only. (see Maintenance)

Maintenance
