w

When the button is pressed the first time, the previous value

is  indicated  in  the  temperature  display  of  the  freezer

compartment.

u

To  change  the  temperature  in  1  °C  steps:  briefly  press  the

button.

-or-

u

To  change  the  temperature  continuously:  hold  down  the

button.

w

The value is displayed flashing during the setting operation.

w

The  actual  temperature  is  displayed  about  5  s  after  the  last

press of a button. The temperature slowly adjusts to the new

value.

5.7.4 SuperFrost

With  this  function  you  can  freeze  fresh  food  quickly  through  to

the  core.  The  appliance  operates  with  maximum  refrigeration.

The noise of the refrigeration unit may be temporarily louder as

a result.
The  maximum  amount  of  fresh  food  which  can  be  frozen  in  24

h  is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".  This  amount  varies  according  to  the  model  and  climate

rating.
You do not have to activate SuperFrost in the following cases:

-

when placing frozen food in the freezer

-

when freezing up to about 2 kg fresh food daily

Freezing with SuperFrost

u

Briefly press the SuperFrost button

 Fig. 3 (4) once.

w

The SuperFrost symbol

 Fig. 3 (5) shines.

w

The  freezer  temperature  drops,  the  appliance  operates  with

maximum refrigerating performance.

For a small amount of food:

u

wait about 6 h.

u

Place the fresh food in the top drawers.

For the maximum amount of food:

u

wait about 24 h.

u

Place  wrapped  food  straight  on  the  shelves  and,  once

frozen, put it into the drawers.

w

SuperFrost  is  automatically  deactivated.  Depending  on  the

quantity  placed  inside,  after  30  h  at  the  earliest,  65  h  at  the

latest.

w

Freezing is concluded.

w

The SuperFrost symbol

 Fig. 3 (5) goes out.

w

The  appliance  continues  to  operate  in  the  energy-saving,

normal mode.

5.7.5 Drawers

Note

The  energy  consumption  increases  and  the  cooling  perform-

ance decreases if there is insufficient ventilation.

For appliances with NoFrost:

u

Leave the bottom drawer in the appliance!

u

Always keep the air slits of the fan free at the rear wall!

u

To store frozen food directly on the shelves: pull the drawer

forwards and lift it out.

5.7.6 Shelves

u

To  remove  the  shelf:  lift  up  at  the  front

and pull out.

u

To  put  the  shelf  back:  simply  push  in  as

far as it will go.

5.7.7 VarioSpace

Apart  from  being  able  to  remove

the  drawers,  you  can  also

remove  the  shelves,  creating

space  for  large  items  of  frozen

food. Poultry, meat, large pieces

of  game  and  high  bakery  prod-

ucts  can  be  frozen  in  one  piece

and prepared.

u

The  maximum  load  of  frozen

food  for  the  drawers  is  25  kg

each  and  for  the  shelves

35 kg each.

5.7.8 Information system

Fig. 17

(1) Ready-made meals, ice

cream

(4) Sausages, bread

(2) Pork, fish

(5) Game, mushrooms

(3) Fruit, vegetables

(6) Poultry, beef/veal

The  figures  indicate  the  storage  time  in  months  for  several

types  of  frozen  food  in  each  case.  Storage  times  given  are

guide times.

5.7.9 Cold storage accumulators

The  cold  storage  accumulators  prevent  the  temperature  from

rising too fast in the event of power failure.
Using cold storage accumulators

u

Place the cold storage accumula-

tors  in  the  top  freezer  compart-

ment to save space.

u

Place  the  frozen  cold  storage

accumulators  on  the  frozen  food

in  the  upper  front  area  of  the

freezer compartment.

6 Maintenance

6.1 Defrosting with NoFrost

The NoFrost system automatically defrosts the appliance.
Refrigerator compartment:
The defrost water evaporates due to the compressor heat.

u

Regularly  clean  the  drain  opening  to  allow  the  water  to  flow

away (see 6.2) .

Freezer compartment:

Maintenance

13
