17

 When adjusting temperature set points, use the following

chart as a guide:

 CONDITION

TEMPERATURE ADJUSTMENT

 Refrigerator too cold

 Refrigerator setting 1° higher

 Refrigerator too warm

 Refrigerator setting 1° lower

 Freezer too cold

 Freezer setting 1° higher

 Freezer too warm/
too little ice

 Freezer setting 1° lower

 Fast Cool

The Fast Cool feature assists with periods of high refrigerator use,
full grocery loads, or temporarily warm room temperatures.

■

To turn on the Fast Cool feature, press and hold the
Refrigerator Temperature button   for 3 seconds. When
feature is activated, the Fast Cool icon will be illuminated. The
Fast Cool feature will remain on for 2 hours unless manually
turned off.

■

To manually turn off the Fast Cool feature, press and hold the
Refrigerator Temperature button   for 3 seconds. The Fast
Cool icon will turn off when feature is not activated.

■

Adjusting refrigerator temperature will automatically turn off
the Fast Cool feature.

 Fast Freeze

The amount of fresh food (in kg) that can be frozen in 24 hours is
indicated on the appliance rating plate.

■

Press Freezer Temperature button   for 3 seconds (until the
Fast Freeze Indicator lights up), 24 hours before placing fresh
food in the freezer. After placing fresh food in the freezer, 24
hours on Fast Freeze function is generally suffi cient; After 50
hrs the fast freeze function automatically deactivates.

■

To manually turn off the Fast Freeze feature, press and hold
the Freezer Temperature button   for 3 seconds. The Fast
Freeze icon will turn off.

■

Adjusting the freezer temperature will automatically turn off
the Fast Freeze feature.

 Holiday Mode

This mode is designed to avoid your appliance from wasting
energy during times when it's not in regular use (when you are in
holiday for example).

By selecting this function the temperature of refrigerator
compartment (RC) will automatically be set to the warmest set
point.

■

To use the Holiday mode, press mode button until Holiday
mode indicator is lit on the display.

■

To exit the Holiday mode, press the mode button until no
mode icon is lit on the display.

■

Adjusting the refrigerator temperature will automatically turn
off the Holiday Mode feature.

IMPORTANT: If this mode is selected then all food and drinks
must be removed from refrigerator compartment.

 Sound ON-OFF

Press button to activate/deactivate Sound Feedback.

 Key Lock

■

Press and hold the Lock button for 3 seconds to activate lock
feature.

■

To deactivate lock, press and hold the Lock button for 3
seconds.

The lock feature will ignore all interaction with control panel until
the user unlocks the control panel. This feature is meant to avoid
unintentional changing of settings.

Demo Mode (only with WQ9 B1L, 6WM591NIHAS and
WQ70900SXX)

This mode is used when refrigerator is on display in a retail shop
or if you want to turn the cooling off and deactivate all other
functions (except interior lighting).

Demo mode can be used when going on extended holiday.
See the “Holiday and Moving Care” section for proper steps on
leaving your refrigerator in this mode for long periods of time.

■

If you turn on Demo mode, the “Demo” icon will light up on
the display.

■

Enter or exit Demo mode by pressing and holding the Sound
On or Off button and the Lock button simultaneously for 3
seconds.

Additional features

Door Open Alarm

■

The Door Open Alarm feature sounds an alarm and blinks the
“Door Open” icon

 when any of the four doors is open for 2

minutes or more.

■

The alarm will repeat every 5 minutes. Close all doors to turn
it off.

NOTE:

 To mute audible alarm while keeping the doors open,

such as while cleaning inside of refrigerator, touch any button on
control panel. The alarm sound will be temporarily turned off, but
the Door Open icon will still be displayed on the control panel.

 Lighting the Refrigerator

The refrigerator has an interior light that comes on any time door
is opened.

NOTE:

 The light is LED which does not need to be replaced. If the

LED does not illuminate when the door is opened, call service to
replace light.
