English

4

5.  Height adjustment lever
6. Handle knob
7. Starter grip
8. Power lever
9.  Rope guide knob
10.

$LU¿OWHU

11. Panel

6LGHGLVFKDUJHGHÀHFWRU

13. Pins
14. Side discharge door
15.

+RRNVRIVLGHGLVFKDUJHGHÀHFWRU

16. Side discharge door opening

ASSEMBLY

UNPACKING

This product requires assembly.

Ŷ

Inspect the product carefully to make sure no breakage
or damage occurred during shipping.

Ŷ

If any parts are damaged or missing, please call your
Ryobi service centre for assistance.

 WARNING

If any parts are damaged or missing do not operate this
product until the parts are replaced. Using a product
with damaged or missing parts could result in serious
personal injury.

 WARNING

Do not attempt to modify the product or create
accessories not recommended for use with the product.

$Q\VXFKDOWHUDWLRQRUPRGL¿FDWLRQLVPLVXVHDQGFRXOG

result in a hazardous condition leading to possible
serious personal injury.

 WARNING

The lawnmower safety systems or features shall not be
tampered with or disabled.

 WARNING

Never attach or adjust any accessory while the mower
is running. Failure to stop the engine may cause
serious personal injury.

 WARNING

To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark
plug wire from the spark plug when assembling parts.

 WARNING

Never operate the mower without the proper safety
devices in place and working. Never operate the mower
with damaged safety devices. Operation of this product
with damaged or missing parts could result in serious
personal injury.

INSTALLATION OF THE PANEL

6HH¿JXUHD

1.  Use a wrench and socket set (not provided) with the

bolts and nuts to secure the panel on the handle.

INSTALLATION

6HH¿JXUH

1.  Place handles in correct operating position and tighten

handle knobs to secure.

NOTE:

 Do not pinch the cable.

Place starter rope in guide on handle.

3.  Install grass catcher or mulching plug.

SETTING BLADE HEIGHT

6HH¿JXUH

When shipped, the wheels on the mower are set to a low-

FXWWLQJ SRVLWLRQ %HIRUH XVLQJ WKH PRZHU IRU WKH ¿UVW WLPH

adjust the cutting position to the height best suited for your
lawn. The average lawn should be between 38 mm to 50
mm during cool months and between 50 mm and 76 mm
during hot months.

To set the blade height:

Ŷ

To raise the blade height, grasp the height adjustment
lever and move it toward the back of the mower.

Ŷ

To lower the blade height, grasp the height adjustment
lever and move it toward the front of the mower.

INSTALLING SIDE DISCHARGE DEFLECTOR (FOR
SIDE DISCHARGE OPERATION)

6HH¿JXUH

NOTE:

 :KHQ XVLQJ WKH VLGH GLVFKDUJH GHÀHFWRU GR QRW

install the grass catcher. The mulching plug should remain
installed.
1.  Lift the side discharge door.

 $OLJQ WKH KRRNV RQ WKH GHÀHFWRU ZLWK WKH KLQJH URG RQ

the underside of the door.

3.

/RZHUWKHGHÀHFWRUXQWLOWKHKRRNVDUHVHFXUHGRQWKH

mulch door hinge rod.

4.

5HOHDVHWKHGHÀHFWRUDQGVLGHGLVFKDUJHGRRU

OPERATION

FUEL AND REFUELLING

 WARNING

$OZD\VKDQGOHSHWUROZLWKFDUHLWLVKLJKO\ÀDPPDEOH
