 English |

15

Bosch Power Tools

F 016 L70 887 | (16.9.13)

Declaration of Conformity

Equipment category: 32
Notified body:

SRL, Sudbury, England, Nr. 1088
Technical file (2006/42/EC, 2000/14/EC) at:

Bosch Lawn and Garden Ltd., PT-LG/ENS4,

Stowmarket, Suffolk IP14 1EY, England

Robert Bosch GmbH, Power Tools Division

D-70745 Leinfelden-Echterdingen

23.07.2013

Mounting and Operation

Starting

For Your Safety



Warning! Switch off, remove the isolator key and the

battery before adjusting, cleaning or if cable is cut,

damaged or entangled.



The blades continue to rotate for a few seconds after

the machine is switched off.



Caution  –  do not touch the rotating blade.

Battery Charging



Do not use other battery chargers.

The supplied battery

charger is designed for the Lithium-Ion battery in your gar-

den product.



Observe the mains voltage!

The voltage of the power

supply must correspond with the data given on the name-

plate of the battery charger. Battery chargers marked with

230 V can also be operated with 220 V.

The battery is equipped with temperature monitoring that al-

lows charging only in the temperature range between 0  ° C

and 45  ° C. In this manner, a high battery service life is

achieved.

Note:

The battery is supplied partially charged. To ensure full

capacity of the battery, completely charge the battery in the

battery charger before using your power tool for the first time.
The lithium ion battery can be charged at any time without re-

ducing its service life. Interrupting the charging procedure

does not damage the battery.
The “Electronic Cell Protection (ECP)” protects the lithium ion

battery against deep discharging. When the battery is run

down or discharged, the garden product is shut off by means

of a protective circuit: The blade no longer moves.

Do not continue to press the On/Off

switch after the garden product has

been automatically switched off.

The battery can be dam-

aged.

Charging Procedure

The charging procedure starts as soon as the mains plug of

the battery charger is plugged into the socket outlet and the

battery   is inserted into the charging compartment  .
Due to the intelligent charging method, the charging condi-

tion of the battery is automatically detected and the battery is

charged with the optimum charging current, depending on

battery temperature and voltage.
This gives longer life to the battery and always leaves it fully

charged when kept in the charger for storage.

Rapid-charging Procedure

3 600 ... HA4 4.. HA4 5..

We declare under our sole responsibility that the product described under “Technical data” is

in conformity with the following standards or standardization documents: EN 60335 accord-

ing to the provisions of the directives 2011/65/EU, 2004/108/EC, 2006/42/EC,

2000/14/EC.

2000/14/EC: Guaranteed sound power level

Conformity assessment procedure according to Annex VI.

dB(A)

89

90

Henk Becker

Executive Vice President

Engineering

Helmut Heinzelmann

Head of Product Certification

PT/ETM9

Action

Figure

Delivery Scope

1

Handle Assembly

2

Snap together the Grassbox
Grassbox fitting/removing

3

Battery Charging

4

Inserting the Battery

5

Insert Isolator Key and fit in the Storage

Position

6

Adjusting the Cutting Height

7

Starting

8

Working Advice

9

Stopping, Remove the isolator key

10

Removing the Battery

11

Blade Maintenance

12

Selecting Accessories

13

AL 3640 CV

Professional

AL 3620 CV

Professional
