30
| English
1 619 929 J53 | (12.5.11)
Bosch Power Tools
21
Allen key (5 mm)
22
Ring spanner (23 mm)
23
Push stick
24
Insert plate
25
Riving knife
26
Saw blade
27
Lens
28
Profile rail
29
Cable holder
30
Retaining bracket for storage of the auxiliary parallel
guide
31
Sawdust ejector
32
Extraction adapter
33
Fixture for storage of the blade guard
34
Insert-plate notches
35
Clamping handle of the parallel guide
36
V-guide of parallel guide
37
Auxiliary parallel guide
38
“Auxiliary parallel guide” fastening kit
39
Guide rail of the angle stop
40
“Profile rail ”fastening kit
41
Fastening screw for sawdust ejector
42
Clamping nut
43
Spindle lock lever
44
Clamping flange
45
Tool spindle
46
Mounting flange
47
Indicator for bevel angle
48
Scale for bevel angle
49
Locking knob for various mitre angles
50
Angle indicator on the angle guide
51
Saw-table clearance indicator
52
ON button
53
Knurled nut for profile rail
54
Phillips screw for adjustment of stop
55
55
Stop for 0 ° mitre angle
56
Screw for bevel angle indicator
57
Phillips screw for adjustment of stop
58
58
Stop for 45 ° mitre angle
59
Front Allen screws (5 mm) for parallelism adjustment of
the saw blade
60
Rear Allen screws (5 mm) for parallelism adjustment of
the saw blade
61
Screw for saw-table clearance indicator
62
Screw for parallel guide clearance indicator
63
Adjusting screws for insert plate
64
Allen key (2 mm)
65
Holder for storage of “auxilliary parallel guide fastening
kit”
66
Retaining clamp for storage of the extraction adapter
67
Fastening nut for the ring spanner and for attaching the
push stick
68
Holder for storage of the Allen key
69
Retaining clamp for storage of the angle stop
70
Adjustment screw for tightening tension of guide
36
* depending on country version
Accessories shown or described are not part of the standard deliv-
ery scope of the product. A complete overview of accessories can
be found in our accessories program.
Technical Data
Noise Information
Measured sound values determined according to EN 61029.
Typically the A-weighted noise levels of the product are:
Sound pressure level 103 dB(A); Sound power level
116 dB(A). Uncertainty K = 3 dB.
Wear hearing protection!
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical Data” is in conformity with the fol-
lowing standards or standardization documents: EN 61029
according to the provisions of the directives 2004/108/EC,
2006/42/EC.
EC Type Certification No. MSR 1034 by notified testing agen-
cy No. 0366.
Technical file at:
Robert Bosch GmbH, Dept. PT/ESC,
D-70745 Leinfelden-Echterdingen
Table saw
GTS 10 J
Professional
Article number
3 601 M30 ...
... 500
... 530
... 570
... 590
... 5P0
... 5R0
... 560
Rated power input
W
1800
1650
No-load speed
min
-1
3650
3650
Reduced starting current
z
z
Weight according to
EPTA-Procedure 01/2003
kg
26
26
Protection class
/
II
/
II
Dimensions (incl. removable product features)
Width x depth x height
mm 578 x 706 x 330
Maximum workpiece dimensions, see page 34.
The values given are valid for a nominal voltage [U] of 230 V. For differ-
ent voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine.
The trade names of the individual machines may vary.
Dimension of suitable saw blades
Saw blade diameter
mm
254
Blade body thickness
mm
1.7 – 1.9
Tooth thickness/setting, min.
mm
2.6
Mounting hole diameter
mm
30
